PEDESTAL PARTS (NOT INCLUDED)
Illus. Part
No. No. DESCRIPTION
Illus. Part
No. No. DESCRIPTION
Illus. Part
No. No. DESCRIPTION
PED2700A
1 Literature Parts
LIT8537141 Installation
Instructions
LIT8537342 Parts List
2 Drawer Front
Assembly
8537870 White
8537871 Biscuit
8537872 Graphite
8537908 Pewter
8537931 Meteorite
3 Drawer Bin
8537883 For Model Numbers
LAB2700MQ,
LAB2700MT,
LAB2700MK and
LAB2700ML
8537934 For LAB2700PMT
4 Divider, Drawer
(Set Of 2)
8537875 For Model Numbers
LAB2700MQ,
LAB2700MT,
LAB2700MK and
LAB2700ML
8537935 For LAB2700PMT
5 8537850 Slide Assembly
6 3400111 Screw
7 8537852 Foot Assembly
8 3400639 Screw, 6−20 x 3/8
9 Cabinet
(Not Serviced)
10 3400842 Screw, 8−18 x 1/2
11 8537863 Pad (4)
12 8537853 Pan, Bottom
13 9740848 Screw
14 90767 Screw
For Model: GHW9160PW0
(White/Platinum)
8180464 14
