Model 414 – White 414 User Manual
Page 15
15
Model 414
REF.
NO.
PART
NO
DESCRIPTION
1
735-0246
Vinyl End Plug
2
647-0014
Clutch Control Ass’y.
3
710-1017
Torx Mach. AB-Tap Scr. 1/4 x .62"
4
786-0131
Handle Cover
5
786-0098
Retaining Brkt.—R.H.
6
786-0118
Retaining Brkt.—L.H.
7
720-0278
Grip (2 Req’d.)
8
720-0210A
Knob
9
712-3008
Hex Jam Nut 3/8-16 Thd.
11
735-0127
Rubber Washer
12
736-0204
Fl-Wash. .344" I.D. x .6" O.D.
13
747-0902
Gear Shift Rod
14
714-0104
Hairpin Clip
15
649-0017
Handle Ass’y.
16
710-0896
Tap Scr. 1/4-14 x 5/8" Lg.
17
726-0330
Cable Clip
21
746-0916
Clutch Cable
22
786-0120
Depth Bar
23
736-0117
Fl-Wash. 3/8" I.D. x 5/8" O.D.
24
710-0253
Hex Bolt 3/8-16 x 1" Lg.*
28
715-0120
Spiral Pin 3/16" x 1"
29
686-0095
Shift Crank Ass’y.
30
711-0415
Clevis Pin
31
714-0149B
Hairpin Clip
32
642-0015
Tine Ass’y.—L.H.
642-0016
Tine Ass’y.—R.H. (Not Shown)
33
786-0090
Side Shield
34
786-0113
Rear Tine Shield
35
686-0044A
End Cover Ass’y.
36
738-0849
Hex Cap Bolt 5/16-18 x 1.25" Lg.
38
710-0376
Hex Bolt 5/16-18 x .75" Lg.
39
710-3097
Carriage Bolt 3/8-16 x 1" Lg.
40
712-0798
Hex Ins. L-Nut 3/8-16 Thd.
43
712-3004A
Hex Flange Top L-Nut 5/16-18
44
786-0076
Tine Shield Brkt.—R.H.
45
786-0077
Tine Shield Brkt.—L.H.
46
711-0415
Clevis Pin .375" Dia.
47
786-0085
Tine Shield
48
747-0432
Tiller Flap Rod
49
726-0106
Cap Speed Nut
50
710-0189
Hex Bolt 5/16-18 x 3" Lg.
51
786-0101B
Shift Cover (410, 412 & 422)
786-0168
Shift Cover (415 & 417)
52
710-1017
Torx Mach. AB-Tap Scr. 1/4 x .6"
54
786-0109
Handle Brkt.—L.H.
55
786-0108
Handle Brkt.—R.H.
56
784-0191
Hex Nut Retainer Brkt.
57
712-0379
Hex Flange Nut 3/8-24 Thd.
58
750-0885
Spacer .322 Dia.
59
784-0190
Handle Adjustment Crank
60
712-0421
Knob 5/16-18 Thd.
61
736-0169
L-Washer 3/8" I.D.
REF.
NO.
PART
NO
DESCRIPTION
PART
NO
DESCRIPTION
777D01165
WOP Handle Panel
777D01168
WOP Belt Guard
777D02432
WOP Engine
777S30038
Rear Tine Warning
777-4102
R N F T
777I20358
Place Hand Here
777I20362
Operating Instructions
777I20363
Shift Cover
777I20364
FNR Front Handle
LABELS
NOTE: For painted parts, please refer to
the list of color codes below. Please add the
applicable color code, wherever needed, to
the part number to order a replacement part.
For instance, if a part, numbered 700-xxxx,
is painted Oyster Gray, the part number to
order would be 700-xxxx-0662.
Oyster Gray: 0662
Powder Black: 0637
