ViewEra V171 - Manual (Page 14)

5. Product Specifications
a. 15”
LCD monitor
Model
Spec
V150
Display type 15” active matrix TFT LCD panel
Pixel pitch 0.297(H) x 0.297(V) mm
Max. resolution 1024(H) x 768(V) XGA
Contrast ratio 400 : 1
Brightness 250 cd/m
2
Response time 25 ms
Display color 16.777M
Viewing angle (H/V) 130° / 100°
Display mode VGA, SVGA
Power consumption ON<48W (maximum)
Signal connector D-sub
Front control Auto adjustment, ,OSD menu, power, “ - “ and “ +“
OSD menu Brightness, Contrast, Auto Adjustment, Clock, Phase, Language and Reset
Power adapter AC Input: 100-240V~1.8A, 50-60Hz; DC Output : 12V/ 3.0A
Weight Net：3.55Kgs , Gross： 5.25Kgs
Set Size 375(H) x 360(V) x 185(D) mm
Page 12
