16
16. ECHO CONTROL FOR MIC-1 AND MIC-2 - This controls the amount of ECHO that microphones 1 and 2 will
receive. Turn clockwise to increase echo and counterclockwise to decrease echo.
17. NTSC/PAL SELECTOR SWITCH - This switch is used to select the NTSC/PAL setting according to country. For
U.S. televisions systems it should be set to NTSC and for European television systems the selector should be set to
PAL.
18. VOLTAGE SELECTOR SWITCH - This switch is used to select the voltage setting according to country. For use in
the U.S. the voltage selector should be set to 110V-120V and 220V-240V in Europe.
Rear panel controls and functions cont.
VIDEO SYSTEM VOLTAGE SELECT
ECHO
NTSC
SWITCH TO
NTSC FOR U.S. TV SYSTEM
PAL FOR EUROPE TV SYSTEM
PAL 110-120V 220-240V
TREBLE
MIC 1-2 CONT
BASS DJ MIC VOL
DJ MIC
ECHO BYPASS
Rear Panel
17 18 16
