SmartPoE/2402M

24 Port 10/100 Managed PoE Switch
with 2 Gigabit Combo

Features

24 Por t 10/100 Managed PoE

Switch with 2 Gigabit Combo

POE-63226T

Feeds PoE to up to 24 devices!

POE-63226T

24 Port 10/100 Managed PoE
Switch w/ 2 Gigabit Combo

POE-DCP248

Twin DC 48V/400W output
power supply

*

POE-DCP148-UPS Single DC 48V/400W output

with UPS power supply

*

P

ART

N

UMBER

D

ESCRIPTION

802.3af

Compliant

Conforms to IEEE802.3 10BASE-T, 802.3u 100BASE-TX/FX,
802.3ab 1000BASE-T, 802.3z Gigabit fiber, 802.3af power
over Ethernet

Port Based VLAN /802 .1Q Tag VLAN

IEEE802.3x Flow control:

– Flow control for full duplex
– Back pressure for half duplex

High back-plane bandwidth 8.8Gbps

IEEE802.3ad Port trunk with LACP

Rapid spanning tree IEEE802.1w

Spanning tree protocol IEEE 802.1d

IGMP snooping and IGMP Query mode for Multi-media
applications

IEEE 802.1p class of service

Port mirror and bandwidth control

IEEE 802.1x user authentication;

TACACS+ (option)

Supports GVRP function

Broadcast storm filter

End point insert mode remote power feeding

DHCP client

Provides extra DC 48V input with redundant function
and management power status through RS-232 port

Online extra power supply testing through RS-232 port

Management by Web/SNMP/Telnet/Console

Supports command line interface management

System event log support

SNTP support

S

EE BACK FOR

F

ULL

S

PECIFICATIONS

908 Canada Court

City of Industry, CA 91748 U.S.A.

Phone: 626.964.7873 or 800.346.6668

Fax: 626.964.7880

www.unicomlink.com

e-mail: [email protected]

©UNICOM 2007. UNICOM is a trademark of UNICOM Electric, Inc. All rights reserved.

Specifications subject to change without notice.

The SmartPoE/2402M is a multi-port switch that can be used to build
high-performance switched workgroup networks.This switch is a store-
and-forward device that offers low latency for high-speed networking and
features a “store-and-forward “switching scheme.This allows the switch to
auto-learn and store source addresses in an 8K-entry MAC address table.
The SmartPoE/802M is targeted at workgroup, department or backbone
computing environments.The SmartPoE/802M has twenty-four auto-
sensing 10/100Base-TX RJ-45 ports and all ports support the PoE injector
function.The switch as two auto-detected Gigabit Combo ports for
higher connection speed.

Also, the SmartPoE/2402M provides one extra 48 VDC power input for
the power supply input connection.

Notes: *

The SmartPoE/2402M switch offers multiple solutions for your

everyday needs. It comes equipped with an internal 200 watt
power supply that can support up to 8.33 watts per port for up to
24 ports or 15.4 watts for up to 12 ports . If your solution requires
the need for full 24 port PoE power, you can attach our optional
Single DC 48V/400W (POE-DCP148-UPS) output power supply
to give you the flexibility of full 24 port PoE power of up to 15.4
watts per port. In addition, if you need to power additional PoE
switches, we offer a Dual DC 48V/400W output power supply
(POE-DCP248) to power up to two extra PoE (PSE) devices.
