SPECIFICATIONS
1. Continuous 4W load 20Hz to 20kHz, < 1% THD, with input voltage at 14.4VDC.
2. Continuous 2W load 20Hz to 20kHz, < 1% THD, with input voltage at 14.4VDC.
Amplifier Section
HP-2300
HP-2400
HP-2600
Power Output 4W
(Watts)note 1
50 x 2
75 x 2
100 x 2
Power Output 2W
(Watts)note 2
75 x 2
100 x 2
175 x 2
Power Output 4W
(Watts) Bridged
150 x 1
200 x 1
350 x 1
Amplifier
Efficiency
> 55% into 2W load
at max. power
> 55% into 2W load
at max. power
> 55% into 2W load
at max. power
Externally
Bridgeable
yes
yes
yes
Remote Bass
Function
yes (HP-RB1
optional)
yes (HP-RB1
optional)
yes (HP-RB1
optional)
Distortion at
Rated Power
< 1.0% THD+N
< 1.0% THD+N
< 1.0% THD+N
Frequency
Response
20Hz to 20kHz
±0.5dB
20Hz to 20kHz
±2.5dB
20Hz to 20kHz
±2.5dB
Linear Bandwidth
10Hz to 50kHz
±3dB
10Hz to 50kHz
±3dB
10Hz to 50kHz
±3dB
Damping Factor
> 200
> 200
> 200
Input Sensitivity
150mV to 5V rms
150mV to 5V rms
150mV to 5V rms
Supply Voltage
Range
9 to 18V
9 to 18V
9 to 18V
Protection
thermal, DC offset,
reverse polarity,
short protection,
under-voltage,
over-voltage
thermal, DC offset,
reverse polarity,
short protection,
under-voltage,
over-voltage
thermal, DC offset,
reverse polarity,
short protection,
under-voltage,
over-voltage
Terminal Wire
Gauge
Power 0/1 AWG,
Remote 12 AWG,
Ground 0/1AWG,
Speaker 12 AWG
Power 0/1 AWG,
Remote 12 AWG,
Ground 0/1AWG,
Speaker 12 AWG
Power 0/1 AWG,
Remote 12 AWG,
Ground 0/1AWG,
Speaker 12 AWG
Input Impedance
20kW
20kW
20kW
Fuse Type
(1) 20 Amp
(1) 30 Amp
(2) 20 Amp
Dimensions
7.5"x10.25 x 2.4"
7.5"x10.25 x 2.4"
10.5"x10.25 x 2.4"
Weight
5.0 lbs.
5.0 lbs.
7.6 lbs.
Crossover Section
High Pass
Crossover
Continuously
variable (50-500Hz)
Continuously
variable (50-500Hz)
Continuously
variable (50-500Hz)
Low Pass
Crossover
Continuously
variable (50-500Hz)
Continuously
variable (50-500Hz)
Continuously
variable (50-500Hz)
Intelli-Bass
yes
yes
yes
