Netopia Network Adapte - Manual (Page 10)

WINDOWS XP HOME/PROFESSIONAL/MEDIA CENTER EDITION
1. Select Start and then Control Panel OR Start and then Settings > Control Panel.
2. Select Network and Internet Connections and then select Network Connections OR double-click on
Network Connections.
3. Double-click on Local Area Connection.
4. Click on Properties.
5. Highlight Internet Protocol (TCP/IP) by clicking on it (do not uncheck the check box).
6. Click on Properties.
7. Select Obtain an IP address automatically.
8. Select Obtain DNS server address automatically.
9. Click OK.
10. Click OK to close the Local Area Connection Properties window.
11. Close the remaining open windows.
WINDOWS 2000
1. Select Start and then select Settings.
2. Select Control Panel.
3. Double-click on Network and Dial-up Connections.
4. Double-click on Local Area Connection.
5. Click on Properties.
6. Highlight Internet Protocol (TCP/IP) by clicking on it (do not uncheck the check box).
7. Click on Properties.
8. Select Obtain an IP address automatically.
9. Select Obtain DNS server address automatically.
10. Click OK and close the remaining open windows.
Macintosh configuration instructions are located on the next page. After you’ve completed these instructions,
please proceed to Configuring Your Wireless DSL Router on the next page.
WINDOWS VISTA
1. Select the Microsoft Orb located in the bottom left corner of your screen and then Control Panel.
2. Under Network and Internet select View network status and tasks.
3. Select Manage network connections.
4. Double-click on Local Area Connection.
5. Click on Properties.
6. Highlight Internet Protocol Version 4 (TCP/IPv4) by clicking on it (do not uncheck the check box).
7. Click on Properties.
8. Select Obtain an IP address automatically.
9. Select Obtain DNS server address automatically.
10. Click OK.
11. Click OK to close the Local Area Connection Properties window.
12. Close the remaining open windows.
Step 3
10
