Network Technologies KEEMUX-P2 - Manual (Page 3)

1
TABLE OF CONTENTS
INTRODUCTION ............................................................................................................................................................................... 1
MATERIALS...................................................................................................................................................................................... 1
FEATURES AND FUNCTIONS......................................................................................................................................................... 2
INSTALLATION ................................................................................................................................................................................ 3
Units with audio support (optional)............................................................................................................................................ 4
Power-Up Sequence .................................................................................................................................................................... 4
Power-Down Sequence ............................................................................................................................................................... 4
USING THE NTI SWITCH ................................................................................................................................................................. 4
Front Panel Control ..................................................................................................................................................................... 4
Keyboard Control......................................................................................................................................................................... 5
COMMAND Mode ..................................................................................................................................................................... 5
SCAN Mode .............................................................................................................................................................................. 5
BROADCAST Mode.................................................................................................................................................................. 5
Keyboard Features .................................................................................................................................................................. 6
AUDIO SUPPORT............................................................................................................................................................................. 6
DUAL VIDEO SUPPORT .................................................................................................................................................................. 6
RS232 CONTROL ............................................................................................................................................................................. 6
TECHNICAL SPECIFICATIONS ....................................................................................................................................................... 8
REMOTE (RMT-2-ST) ....................................................................................................................................................................... 9
TROUBLESHOOTING ...................................................................................................................................................................... 9
INTRODUCTION
The KEEMUX-P2 switch allows one user to access two PS/2 CPUs with only one keyboard, monitor and mouse. Internal auto-
boot circuitry allows both CPUs to boot simultaneously and error-free without the need for a keyboard, monitor and mouse on
each CPU.
Available Options
•
A KEEMUX-P2 can be ordered that supports a hard-wired remote control (RMT-2-ST) for increased user control flexibility.
Add "-RMT" to the part number. (i.e. KEEMUX-P2-RMT) The RMT-2-ST remote (ordered separately) comes standard with
a 6 foot cable but a cable of up to 100 feet can be ordered
(DKEXT-35/50/75/100).
• Audio support to enable user to connect stereo speakers to receive audio signals from connected CPUs- add "-AUD" to the
part number (i.e. KEEMUX-P2-AUD)
• RS232 support for alternative control using RS232 connection. Add "-RS" to the part number (i.e. KEEMUX-P2-RS)
• Dual Video option supports CPUs with two video outputs. Add "-DV" to the part number (i.e.KEEMUX-P2-DV)
See our catalog, visit our website at
http://www.nti1.com , or contact your NTI sales representative for more details.
MATERIALS
Materials Supplied with this kit:
•
NTI KEEMUX-P2 PS/2 KVM Switch
Additional material supplied when model includes AUD, RS, or DV option:
•
120VAC or 240VAC at 50 or 60Hz-9VDC/0.5A AC Adapter
Materials Not Supplied, BUT REQUIRED:
A set of 2 cables for each CPU being connected to the switch must be used:
PS/2 CPU to switch
• VEXT-xx-MM
• (1) VVKINT-xx-MM for keyboard and mouse interface.
OR
(2) VKINT-xx-MM for keyboard or mouse interface
