38

Chapter 3 Installing the shelf, OADM, and OMUX

212257-B

Figure 15 Shelf with plug-in module in 19-inch rack

Inserting a CWDM OADM or a CWDM OMUX

CWDM OADMs and CWDM OMUXs are passive devices that require no power
for their operation. You can insert them in the optical shelf (

Figure 15

) and then

connect them into your network.

Fail

Pass

10334FA

Optical shelf
