Specifications, Output characteristics – National Instruments 8-Channel Solid-State Relay (SSR) Digital Output NI 9485 User Manual
Page 13

© National Instruments Corp.
13
NI 9485 Operating Instructions
Typically, when a system is in sleep mode, you cannot
communicate with the modules. In sleep mode, the SSRs open to
prevent current from flowing through the load. Consequently, the
system consumes minimal power and may dissipate less heat than
it does in normal mode. Refer to the Specifications section for more
information about power consumption and thermal dissipation.
Specifications
The following specifications are typical for the range –40 to 70 °C
unless otherwise noted.
Output Characteristics
Number of channels.......................... 8 digital output channels
Relay type ......................................... Normally open solid-state
relay (SSR)
Switching voltage ............................. 60 VDC max, 30 V
rms
max
