C U S T O M E R S E R V I C E A N D

T E C H N I C A L S U P P O R T

iWARE are registered trademarks of Niles Audio Corporation. SmartDock is a trademark of Niles Audio Corporation.

All other trademarks are the property of their respective owners. Niles reserves the right to change speciﬁcations,

descriptions and prices without notice. The technical and other information contained herein is not intended to set

forth all technical and other speciﬁcations. Designed and engineered in the USA. DS00512A

B Y P H O N E ( I N U S A )

1 - 8 0 0 - B U Y - H I F I ( 2 8 9 - 4 4 3 4 )

B Y P H O N E ( O U T S I D E U S A )

1 - 3 0 5 - 2 3 8 - 4 3 7 3

C U S T O M E R S E R V I C E H O U R S

8 : 0 0 A M t o 5 : 3 0 P M E S T

T E C H N I C A L S U P P O R T H O U R S

8 : 0 0 A M t o 7 : 0 0 P M E S T

O N T H E W E B

w w w . n i l e s a u d i o . c o m

E M A I L T E C H N I C A L S U P P O R T

t e c h s u p p o r t @ n i l e s a u d i o . c o m

E M A I L F O R P R O D U C T S U G G E S T I O N S

p r o d u c t s u g g e s t i o n s @ n i l e s a u d i o . c o m

C O N G R A T U L A T I O N S !

Thank you for choosing the iWare

ES1 Extender System from Niles Audio Corporation. With

proper installation and operation, you’ll enjoy years of trouble free use.

The ES1 Extender System is a pair of wall plates that allow an iPod

to be placed up to

100 meters away from an IntelliControl

ICS Modular MultiZone Receiver or other home

entertainment system that it is to be connected to. The input plate has a 30-pin connector
for the iPod cable and a connection for the power supply. The output plate has a 30-pin
connector for the system connection. Both plates have two CAT5 connectors on the back
that carry audio, video, data and other signals between them that allow you to listen to
and control your iPod.

Niles manufactures the industry’s most complete line of custom installation components
and accessories for audio/video systems. To see the complete Niles product assortment,
visit us on the Internet at www.nilesaudio.com.

•

Extend the reach of an IntelliControl

ICS Modular MultiZone Receiver,
or any 30 pin iPod enabled home
theater system, to an iPod from 3
feet to 300 feet

•

Balanced/differential audio to

preserve audio quality and reject
noise and hum pickup. Also prevents
mutual cross-talk between the audio,
video, and RS232.

•

Balanced/differential video to

preserve video quality and reject
noise and hum pickup. Also prevents
mutual cross-talk between the audio,
video, and RS232.

•

LED on the Input Plate and Output

Plate to indicate that the 12V power
supply is connected and that the
“receiver/ICS” system is connected.

K E Y F E A T U R E S

E S 1 E x t e n d e r S y s t e m U s e r M a n u a l

ES1

Extender System

Wall-Mount Extender System for iPod®

USER MANUAL

P R O D U C T O V E R V I E W

Package Contents
•

ES1 input wall plate

•

ES1 output wall plate

•

2 white Decora

cover plates

•

One 12V in-line power supply

Specifications
•

Power: 12V DC @ 1A

•

Dimensions:

2.75" W x 4.5" H

•

2-year Limited Warranty

LED

Indicates that the power supply

is plugged in (input plate)

and that a system receiver is

connected (output plate)

30 Pin Connector

For connecting an iPod

(input plate) and the system

receiver (output plate)

12V Power Supply

Connector

ES1 Input Wall Plate

ES1 Output Wall Plate

2.75"

1.3"

2.6
