2. Installation

2-6. Connecting the Supplied Power Cable

Connect the supplied power cable to the Switcher.

First connect the supplied power cable’s three-pin plug to the AC IN of the Switcher, and then connect the other plug of the

supplied power cable in the wall outlet.

M a k e s u r e t h a t t h e
prongs are fully inserted
into both the AC IN and
the wall outlet

Ferrite clamp
core (supplied)

NOTE

• Always mount the ferrite clamp core to the power cable. The ferrite clamp core should be mounted as close

to this unit as possible.

• Do not unplug the power cable from the wall outlet or switcher when the switcher is powered on. Doing so

can cause damage to the AC IN connector of the switcher and (or) the prong plug of the power cable.
Carefully operate the unit when “Power ON” or “Please wait” is displayed on the LCD screen in particular.
