MMIC wideband amplifi er
BGA2714

Best-in-class LNB performance

Key features

Ñ Extremely fl at gain curve (21 dB ± 1 dB up to 2.5 GHz)
Ñ Wide frequency range (up to 2.7 GHz @ 3 dB

gain bandwidth)

Ñ Internally matched to 50 Ω
Ñ Very low current (4.6 mA @ 3 V)
Ñ Low supply voltage (3 V)
Ñ Good linearity
Ñ Low noise (2.2 dB @ 1 GHz)
Ñ Excellent reverse isolation (> 50 dB up to 2 GHz)
Ñ Unconditionally stable
Ñ Very few external components required
Ñ Compact SOT363 package

Key applications

Ñ LNB IF amplifi er
Ñ General-purpose low-noise wideband amplifi er

for frequencies up to 2.7 GHz

Our MMIC wideband amplifi er BGA2714 is designed to
meet the specifi c needs of LNB designs. It operates from
a conveniently low supply voltage with a low supply current.

Improve the performance of your LNB design with our MMIC wideband amplifi er BGA2714.
It delivers best-in-class performance at very low current, is small and needs very few external
components. In short, it’s the ideal 1st stage IF amplifi er for LNBs and other low-noise
wideband applications.

A demoboard is available to help further
simplify your design-in process

In addition, it delivers industry-leading performance with a
wide frequency range, high and fl at power gain and low noise.
Supplied in a compact, industry-standard SOT363 package,
it simplifi es system integration.

MMICs like NXP Semiconductors’ BGA2714 are smart RF
solutions that automatically compensate for temperature and
process variations. They integrate transistors, resistors and
capacitors into a single device, reducing component count
and simplify design. In fact, with the BGA2714 you need just
two coupling capacitors and an RF decoupling capacitor.
