Engine Operating Guidelines
OURGP12,0000076 –19–09SEP04–2/4
RG8028A –UN–15JAN99
Crosshatch Pattern On Oil Dipstick
A—Crosshatch Pattern On Oil Dipstick
IMPORTANT: DO NOT add makeup oil until the oil
level is BELOW the ADD mark on
dipstick. John Deere ENGINE BREAK-IN
OIL (TY22041) should be used to make
up any oil consumed during the
break-in period.
3. Check engine oil level more frequently during engine
break-in period. If oil must be added during this period,
John Deere ENGINE BREAK-IN OIL is preferred. See
ENGINE BREAK-IN OIL, in Fuels, Lubricants, and
Coolant Section.
IMPORTANT: DO NOT use PLUS-50

Engine Oil
during the break-in period of a new
engine or engine that has had a major
overhaul. PLUS-50

oil will not allow a
new or overhauled engine to properly
wear during this break-in period.
DO NOT fill above the crosshatch
pattern (A) or the FULL mark, whichever
is present. Oil levels anywhere within
the crosshatch are considered in the
acceptable operating range.
Specification
Engine 1 —Oil Pressure at Full
Load Rated Speed 345
±
103 kPa (3.45
±
1.03 bar)
(50
±
15 psi)
.................................
Minimum Oil Pressure at Rated
Speed
275 (2.75 bar) (40 psi) .....................................................................
Minimum Oil Pressure at 850 rpm 105 kPa (1.05 bar) (15 psi) .................
Coolant Temperature Range 82
°
–94
°
C (180
°
–202
°
F) ................................
PLUS-50 is a trademark of Deere & Company.
1 At normal operating temperature of 115
°
C (240
°
F) sump.
Continued on next page
15-7
