PORT-A-COOL® Hazardous Location Units *
A-2
APPENDIX A
Port-A-Cool®
TEMPERATURE OUTPUT CHARACTERISTICS
30% TO 45% RELATIVE HUMIDITY
DRY BULB
Temp. °C Temp. °F
26.7 80
29.4 85
32.2 90
35.0 95
37.8 100
40.6 105
TEMP. °F
Difference Drop
34 24.5
35 25.2
35 25.2
36 25.9
37 26.6
38 27.4
OUTPUT TEMP.
°C °F
13.3 56
15.6 60
18.3 65
20.6 69
22.8 73
25.6 78
DRY BULB
Temp. °C Temp. °F
23.9 75
26.7 80
29.4 85
32.2 90
35.0 95
37.8 100
TEMP. °F
Difference Drop
30 21.6
31 22.3
30 21.6
32 23.0
32 23.0
33 23.8
OUTPUT TEMP.
°C °F
11.7 53
14.4 58
17.2 63
19.4 67
22.2 72
24.4 76
WET BULB TEMPERATURE
DRY BULB TEMPERATURE
TEMPERATURE DIFFERENCE
TEMPERATURE DROP
OUTPUT TEMPERATURE
Wet Bulb Temperature @ Current Humidity Level
Current Ambient Air Temperature
Dry Bulb Temp Minus Wet Bulb Temp
Temperature Difference Multiplied by 72%
Dry Bulb Temperature Minus Temperature Drop
30% RH
35% RH
DRY BULB
Temp. °C Temp. °F
29.4 85
32.2 90
35.0 95
37.8 100
40.6 105
43.3 110
TEMP. °F
Difference Drop
27 19.4
28 20.2
29 20.9
27 19.4
29 20.9
28 20.2
OUTPUT TEMP.
°C °F
18.9 66
21.1 70
23.3 74
27.2 81
28.9 84
32.2 90
40% RH
DRY BULB
Temp. °C Temp. °F
29.4 85
32.2 90
35.0 95
37.8 100
40.6 105
43.3 110
TEMP. °F
Difference Drop
24 17.3
25 18.0
25 18.0
25 18.0
25 18.0
25 18.0
OUTPUT TEMP.
°C °F
20.0 68
22.2 72
25.0 77
27.8 82
30.6 87
33.3 92
45% RH
