List, Prt-2 – Panasonic AW-PH405 User Manual
Page 3
Ref. No.
Part No.
Part Name & Description Pcs
Remarks
Ref. No.
Part No.
Part Name & Description Pcs
Remarks
PRT-2
1
P40B0D01P001
UPPER CHASSIS
1
2
P45B0D01P002
BASE
1
3
P40B0D01P010
BASE OPTION PANEL
1
4
P45B0D01MK51 D-SUB CONNECTER PANEL ASS’Y
1
5
P45B0D01MK01 HOUSING CASE UNIT
1
5-1
P45B0D01MK52 HOUSING CASE ASS’Y
1
5-2
P45B0D01MK53 TALLY LAMP ASS’Y
1
5-3
P40B0D01P006
TALLY BLANK PANEL
1
6
P45B0D01MK02 BOARD COVER UNIT
1
6-1
P45B0D01MK54 COVER ASS’Y
1
7
P45B0D01MK03 UPPER CONNECTER PANEL UNIT
1
7-1
P45B0D01MK55 UPPER CONNECTER PANEL ASS’Y
1
8
P45B0D01MK04 BASE CONNECTOR PANEL UNIT
1
8-1
P45B0D01MK56 BASE CONNECTOR PANEL ASS’Y
1
8-2
P45B0D01MK57 BASE STOPPER ASS’Y
1
9
P45CMA01MK01 CAMERA ARM UNIT
1
9-1
P45CMA01MK51 ARM ASS’Y
1
9-2
P45CMA01MK52 CAMERA BASE ASS’Y
1
9-3
P45CMA01MK53 CAMERA SCREW ASS’Y
1
10
P45GYU01MK51 GEAR CASE ASS’Y
2
11
P45GYU01MK52 PAN GEAR BOX ASS’Y
1
12
P45GYU01MK53 TILT GEAR BOX ASS’Y
1
13
P45GYU01MK54 GEAR BOX MOTOR ASS’Y
2
14
P45GYU01MK55 GEAR BOX POTENTIO ASS’Y
2
15
P45GYU01B108 GT BELT
2
16
P45DAC01MK01 AC ADAPTER UNIT
1 AW-PH405N
P45DAC01MK02 AC ADAPTER UNIT
1 AW-PH405E
P45DAC01MK03 AC ADAPTER UNIT
1 AW-PH405MC
16-1
P45DAC01MK51 DC FILTER BOARD ASS’Y
1
16-2
P45DAC01MK52 POWER RECTIFIER ASS’Y
1
16-3
P45DAC01MK53 ADAPTER COVER ASS’Y
1 AW-PH405N
P45DAC01MK54 ADAPTER COVER ASS’Y
1 AW-PH405E
P45DAC01MK55 ADAPTER COVER ASS’Y
1 AW-PH405MC
17
J0KG00000012
FERRITE CORE
5
18
J0KG00000011
FERRITE CORE
1
E1
VJBB0451
CPU P.C.BOARD
1 (RTL)
E2
VJBB0452
DRIVER P.C.BOARD
1 (RTL)
E3
VJBB0500
COMP P.C.BOARD
1 (RTL)
E4
VJBB0501
CONNECTOR P.C.BOARD
1 (RTL)
E5
VJBB0502
DC/DC P.C.BOARD
1 (RTL)
E6
VJBB0503
DC FILTER P.C.BOARD
1 (RTL)
E7
VJBB0453
FILTER P.C.BOARD
1 (RTL)
E8
VJBB0522
AC/DC FILTER P.C.BOARD
1 (RTL)
101
P45HAS01P001 CAMERA I/F CABLE
1
102
P45HAS01P002 LENS RD CABLE
1
103
P45HAS01P003 LENS I/F CABLE
1
104
P45HAS01P004 ND/EXT CABLE
1
105
P45HAS01P005 SDI CABLE
1
106
P45HAS01P006 AUX CABLE
1
107
P45HAS01P008 TALLY SW CABLE
1
108
P45HAS01P010 MOTOR CONTROL CABLE
1
109
P45HAS01P011 P/T CONTROLLER CABLE
1
110
P45HAS01P012 CPU POWER CABLE
1
111
P45HAS01P013 DRIVER POWER CABLE
1
112
P45HAS01P014 CN POWER CABLE
1
113
P45HAS01P015 POWER CABLE
1
114
P45HAS01P016 COMP POWER CABLE
1
115
P45HAS01P017 FG1 CABLE
1
116
P45HAS01P018 FG2 CABLE
1
117
P45HAS01P019 THERMISTOR CABLE
1
118
P45HAS01P023 LENS P/S CABLE
1
AW-PH405N
201
VGNB0154
MAIN LABEL
1
202
V7MA0270A4
FUSE REPLACE LABEL
2
203
VQLB0227
SWITCH LABEL
1
204
A7SA0689A4
EARTH MARK LABEL
1
205
V7MA0099B4
SCREW CAUTION LABEL
2
206
V7MA0338A4
SEE MANUAL LABEL
2
207
VQLB0090
EARTH CAUTION LABEL
1
208
VQLB0077
SETTING LABEL
1
209
V7MA0106A4
CAUTION LABEL
1
210
V7MA1006A4
PL CAUTION LABEL
1
213
VQL0L14
SERIAL NUMBER LABEL
1
AW-PH405E
201
VGNB0155
MAIN LABEL
1
202
V7MA0270A4
FUSE REPLACE LABEL
2
203
VQLB0227
SWITCH LABEL
1
204
A7SA0689A4
EARTH MARK LABEL
1
205
V7MA0099B4
SCREW CAUTION LABEL
1
206
V7MA0338A4
SEE MANUAL LABEL
2
208
VQLB0077
SETTING LABEL
1
213
VQL0L14
SERIAL NUMBER LABEL
1
AW-PH405MC
201
VGNB0156
MAIN LABEL
1
202
VQLB0075
FUSE REPLACE LABEL
2
204
A7SA0689A4
EARTH MARK LABEL
1
205
3PC001356AAA SCREW CAUTION LABEL
1
206
3PC001361AAA SEE-MANUAL LABEL
2
208
VQLB0078
SETTING LABEL
1
211
VQLB0071
PRODUCT LABEL
3
212
3PD003493AAA EPUP MARK LABEL
1
213
VQL0L14
SERIAL NUMBER LABEL
1
