10
SYSTEM INFORMATION
Please note that the following functions were added to
improve the operation of the combination cameras.
■ Additions
● Selection of Pan/Tilt Speed
The Pan/Tilt speed can be changed by selecting a mode in
the menu (A1) displayed on the LCD display of the con-
troller.
1. Select the desired monitor and camera.
2. Select a mode by pressing the F3 or F4 button.
“❑” indicates the currently selected mode.
SLW: Moves the Pan/Tilt Head at lower speed.
FST: Moves the Pan/Tilt Head at higher speed.
3. Move the Joystick to move the Pan/Tilt Head in the
desired direction.
Note: Changing the Pan/Tilt speed by pressing the
STOP/SLOW button is enabled only when FST
mode is selected.
The above function is available in a system that includes
the following equipment:
WJ-SX550 Series Matrix Switcher
CPU Ver. 6.00 or later
Control Ver. 6.00 or later
WV-PB5548 Data Board Ver. 6.00 or later
■ Version Information
● WJ-SX550 Series Matrix Switcher
The onscreen display indicates the version in “Cold Start”
or “Normal Start” during the power up procedure.
Note: x.xx is a version number.
Camera cc A1
Monitor mm SLW
FST
F3 F4 F2 F1
M a t r i x S w i t c h e r
R O M
C P U
V e r .
C o n t r o l
A l a r m
X . X X
X . X X
X . X X
X . X X
X . X X
N o . 1
O u t p u t
R S - 4 8 5 N o . 1
N o . 1
C P U
U n i t
P o s i t i o n
0 1
V i d e o
C h a r a c t e r
V D / V S
M o d e l W J - S X 5 5 0 C
T y p e
B o a r d S W .
N o .
N T S C
1
V S
" N o r m a l S t a r t "
