7.3 Antenna connector SMA (female)
A quad band antenna (GSM850/EGSM900/DCS1800/PCS1900) can be
connected to the RF interface. The connection is implemented as a 50 Ω SMA
(female) coaxial jack.
Pin assignments:
Signal name
Pin
Function
RF
Input
RF Input/Output
GND
Output
Frame connecting
