4-3
Item Pitco Frialator Quantity
Number Part Number Description Per Unit
1 B4509601 SCREEN 1
2 P0075300 SCREW, #10 SELF DRILL 2
3 A1101602 BASKET HANGER 1
4 B3401801 TANK 1
5 PP10752 SCREW, 10-24 PAN HEAD 6
6 P0075400 SCREW, #10 SELF DRILL 7
7 B1812601 COVER, REAR 1
8 B3312201 HOSE, OVERFLOW 1
9 PP10388 CLAMP 1
10 P6071223 GROMMET 1
11 B1812301 CABINET 1
12 P0075300 SCREW, #10 SELF DRILL 2
13 A1817902 BRACKET, MAGNET CATCH 1
14 B7230203 HINGE, UPPER RIGHT 1
15 P0075300 SCREW, #10 SELF DRILL 2
16 B3800902 HINGE, LOWER RIGHT 1
17 P0075300 SCREW, #10 SELF DRILL 2
18 B2301501 DOOR 1
19 P0075300 SCREW, #10 SELF DRILL 2
20 P5047581 T-STAT 1
21 PP10839 PLUG, SS 1
22 PP10565 DRAIN VALVE 1
23 A2805902 RACK, ELEMENT 1
24 PP10019 NUT, 10-24 SS KEEP 2
25 P5046965 ELEMENT, 208 VAC 1
P5046968 ELEMENT, 240 VAC 1
PP10829 ELEMENT, 380 VAC 1
26 A1400302 CLAMP, T-STAT 1
27 PP10698 SCREW, 10-24 RH SS 2
28 A1400302 CLAMP 1
29 PP10665 SCREW, 10-24 X 3/8 2
30 B3612901 FRONT PANEL ASSEMBLY (SEE FIGURE 4-4) 1
31 REAR ENTRANCE BOX (SEE FIGURE 4-3) 1
32 FRONT ENTRANCE BOX (SEE FIGURE 4-2) 1
33 P6071300 MAGNET, DOOR
Revised 12/13/93
Table 4-1. Overall Exploded View
