All technical features and data are subject to changes without notice, resulting from continuous development and improvement.
Product Leaflet Date of issue Revision / Date of revision
MEW00341 2003-02-05 2 / 2005-12-06
Type number
2217 External indicator (LED); Including the frame and two screws for the lid.
The input is polarised. J1:1 (+) and J1:2 (-)
Mounting holes (in the lid): c/c = 60 mm.
Technical data
Voltage (V DC) 5 - 24
Current consumption (mA). 1
Ambient temperature (
°C)
operating
storage -20 to +40
-40 to +70
Ambient humidity (% RH) max. 90, non condensing
Ingress Protection rating (estimated) IP42
Size W x H x D (mm)
Lid
Lid + frame
LED lens Ø x H (mm) 84 x 84 x 11.5
84 x 84 x 27.5
8 x 6.5
Weight (g) 43 (frame incl.)
Construction / Colour ABS / Polar white (NCS S 0502-Y)
Approvals
