VQT2G37 (ENG)
8
Before Use
Names of the Components
1 Flash
2 Self-timer indicator
AF assist lamp
3 Lens
4 LCD monitor
5 [MODE] button
6 [REC]/[PLAYBACK] selector switch
7 Speaker
8 [MENU/SET] button
9 Keypad light
10 [Q.MENU]/Delete button
11
[DISPLAY] button
12 Cursor buttons
A: 3/Exposure compensation/Auto
Bracket/White balance fine
adjustment
B: 1/Flash setting button
C: 2/Self-timer button
D: 4/Macro Mode
AF Tracking
In these operating instructions, the cursor buttons are described as shown in the
figure below or described with
3/4/2/1.
e.g.: When you press the 4 (down) button
or Press 4
1 3 2
8 7 4 6
10 11 9 12
5
