AC IN (AC inlet)

This is the AC input terminal.

POWER switch (ON : , OFF :

)

This switch turns the AC adapter on and off.

POWER lamp

This lamp lights green when the POWER switch is set to on.

DC OUT

This is the DC output terminal.
This terminal enables connection of a DC cord.

AC Adapter

2

3

4

1

Controls and Their Functions

(continued)
