- 17 -
VII .SPECIFICATIONS
Metal Cutter (EY3552)
Motor voltage 18 V DC
Blade Speed 2900 /min (rpm)
Blade Size
Outside diameter
Arbor size 165 mm (6-1/2")
20 mm (25/32")
Maximum cutting depth 3 - 56 mm (1/8" - 2-13/64") ( φ 165 mm blade)
Dimensions (L × W × H)
345 Ч 198 Ч 264 mm
(13-37/64" Ч 7-51/64" Ч 10-25/64")
Weight (with battery pack) 4 k g (8.82 lbs)
Battery Pack (EY9251)
Storage Battery Ni-MH Battery
Voltage 18 V DC (1.2 V × 15 cells)
Battery Charger (EY0110)
Model EY0110
Electrical rating See the rating plate on the bottom of the charger.
Weight 0.78 k g (1.72 lbs)
Charging time 65 minutes (EY9251)
NOTE:
• Do not charge “Y” type Ni-Cd battery packs.
• For applicable battery packs to this charger, see the label on the charger or the latest general catalog.
The instruction label on the battery packs also shows the applicable charger.
