ENERGY SAVING
The T-Series is Energy Star compliant. It contains special hardware that provides energy-
saving, automatic Stand By and Shut OFF features. After a period of time,as little as three
seconds, the monitor will automatically power down until the mouse or keyboard are in use.
Automatic Stand By and Shut OFF are set through a software progr am on your
computer.
DM -5948S Power consumption:
Power on Stand by Suspend Off
220 W Max 35 W 8 W 8 W
DM -6952S Power consumption:
Power on Stand by Suspend Off
230 W Max 35 W 8 W 8 W
DM -7752S Power consumption:
Power on Stand by Suspend Off
250 W Max 35 W 8 W 8 W
SIMPLE TROUBLESHOOTING
1. LED not lit: check the connection of power cord press the main power button.
2. No input signal: check the connection of signal cable.
3. The display has a color error, check the pins of the signal cable.
4. Degaussing problems, When operating the monitor, users may find out that putting the
monitor in different locations or switching directions may render the screen’s display
colors abnormal. It is caused by the influence of the earth’s magnetic field. After you
push the “DEGAUSS” key, the colors should become normal again.
5. If the display becomes abnormal due to an electrostatic anomaly, switch the power switch
on the monitor off wait for five seconds, then on the monitor should function normally.
6. No picture on VGA1 or VGA2 (if connected). Monitor may be in standby mode. Make
certain your computer is set to output a signal to the monitor, and it is within the
frequency range of the T series monitor. Refer to Page 2 and Appendix B.
If the computer is set to output a signal to the monitor, move the mouse or perform
keystroke functions to bring the monitor out of standby (sleep) mode.
14
Model:DM -5948S Specifications
CRT Size/Type 29” Super flat square screen with 108 degree magnetic deflection, dynamic
focus forming,49% transmission.
Dot Pitch 0.74
Maximum Resolution XGA;1024 768 @60Hz
Maximum TV Resolution 525 lines (NTSC) ot 625 lines (PAL)
Recommended Resolution 800 600 @75Hz
Display Colors Unlimited
Active Display Area Default : 20.50in 15.35in; 520mm 390mm
H-Frequency 30KHz to 52KHz auto sync
V-Frequency 50Hz to 120Hz
Compatibility VESA  640 480 @ 60Hz, 800 600 @ 60Hz, 1024 768 @ 60Hz
VESA  640 480 @ 72Hz, 800 600 @ 72Hz
VESA  640 480 @ 75Hz, 800 600 @ 75Hz
VESA  640 480 @ 85Hz
NTSC 3.58MHz or PAL 4.43MHz
HDTV READY 480P, 720P, 1080i
Tuner NTSC (68CH CATV 125CH)
Input Signal Video : Analog (0.7Vp-p)
Sync. : Separate Sync. TTL Leve l Positive/Negative
Composite Sync. TTL Level Positive/Negative
Input Connector/Cable RGBHV in #1 - 15 pin D (VGA), Mini-jack audio, on back panel
RGBHV in #2 - 15 pin D (VGA), RCA jack Left, Right, on front panel
RGBHV out - 15 pin D (VGA), RCA jack Left, Right, on back panel.
Switched depending on
RGBHV#1 or RGBVH#2.
Antenna / CATV in - F connector on back panel
Composite Video in - RCA jacks, Composite Video, Audio Left and Right o n
back panel
Composite Video out - RCA jacks, Composite Video, Audio Left and Right
on back panel
S-Video in - Mini Din connector, RCA jack Audio Left and Right on back
panel
Y, Pb, Pr , HDTV mode audio in Left and Right RCA jacks on back panel
Video Dot Clock 65.0MHz
User Controls Power, TV mode, Composite Video mode, S-Video mode, Computer input #1,
Computer input #2 , Channel Select, Numeric keypad, Auto, Mute, CH-LOCK, PIC-
STD, PIC/Page, PIC-Sel, Sleep, Add/Erase, Disp, MTS, System, Fine Tuning, Jump,
Field, Lang, CAP/TXT, CCD, Contrast, Brightness, H. size, H. Position, V. Size
Position, Pincushion, Trapizoid, Bow, Parallelogram, Rotation, Bass, Treble, Balance,
Volume, Sub-Woofer, Background, Instant On, Moire, Red, Green, Blue, Degauss,
Recall, Color Recall.
Audio Power 12W 2
Audio Frequency Response 30Hz to 20KHz
Dimension (w h d) Unit : 27.95in 23.15in 20.04in ; 710 (W) 588 (H) 509 (D)
Carton : 30.49in 27.5 0in 33.42in ; 772 (W) 698 (H) 595 (D)
Weight Net : 103 .4lbs; 47Kg Gross : 123.2 .bs; 56 Kg
Power Supply Auto-switch, 90 - 240V, 50/60Hz
Power Consumption 220W typical
Power Management Off 8W; Suspend 8W; Stand by 35W; Power on 230W Max
Agency Approvals FCC-class B, UL  , CUL  , DHHS
