– 19 –

Mounting the viewfinder

1

Align the positions of the marks (red), and fit into place.

2

Turn the viewfinder locking ring to lock the viewfinder into place.

Viewfinder locking ring

The viewfinder can be turned by 90 degrees by loosening the locking ring.

Viewfinder

Marks (red)
