PICO MACOM INC. 12500 Foothill Blvd. • Lakeview Terrace, CA 91342 • (818) 897-0028 (800) 421-6511 • FAX (818) 834-7197
and Specifications
D E S C R I P T I O N S
3
Description
The TA-52 is a 52 dB gain UHF/VHF/FM
broadband distribution amplifier designed
to function as a reliable key component in
medium and large MATV systems. Signal
control is provided through front panel
design. The UHF/VHF input may be combined or separated by use of a single
throw switch. Low band VHF, High band
VHF and UHF frequencies have separate gain
c o n t r o l s a n d s w i t c h a b l e 1 0 d B i n p u t
attenuators. Features include switchable FM
trap and -20 dB test point.
Features
• 60 dBmV output capability
• Switchable input attenuators
• Output monitor test points
• Switchable FM trap
Specifications
• Slope controls on VHF low and high-
band
• Independently adjustable VHF-High,
VHF-Low and UHF gain levels
• Separate or combined inputs
Bandwidth:
Low band 54-108 MHz
High band 174-216 MHz
UHF band 470-806 MHz
Gain (minimum): 48 dB
Output Capability: 60 dBmV @-50dB
cross modulation
level (3 channels)
Gain Control Range: 10 dB minimum
Max. Input Level: 3 channels @ 8
dBmV per band
Input Attenuators: 10 dB
FM Band Rejection Switch:
95 - 108 MHz -20 dB minimum
Impedance, Input and Output: 75 ohms
Power Requirements: 115 Vac, 60Hz, 25W
Dimensions: 17"L x 3"D x 5"H
Weight: 7.75 lbs.
