MSP7162 GPON RG Fiber Access Residential Gateway
Corporate Head Office:
PMC-Sierra, Inc.
Mission Towers One
3975 Freedom Circle
Santa Clara, CA, 95054, U.S.A.
Tel: 1.408.239.8000
Fax: 1.408. 492.1157
Operations Head Office:
PMC-Sierra, Inc.
100-2700 Production Way
Burnaby, BC V5A 4X1 Canada
Tel: 1.604.415.6000
Fax: 1.604.415.6200
Product Highlights
System Processor
•
MSP7100 Series multithreaded core
•
32 KB zero wait state scratchpad
•
DSP extensions for efficient voice processing
•
32-bit, 233-MHz multi-service bus with multi-master access
Flexible, programmable, hardware-based QoS multi-service bus
arbitration allows provisioning of system bandwidth for high
throughput peripherals
•
Support for multiple transaction priority levels
•
DDR2 SDRAM
Interfaces
•
Integrated ITU-T G.984 compliant GPON MAC and SERDES
•
Line rate operation – 2.488 Gbit/s downstream; 1.244 Gbit/s
upstream
•
Supports 8 T-CONTs
•
Supports 256 Port IDs
•
Supports NSR/SR DBA
•
US and DS FEC
•
AES decryption
•
Multi-queue QoS support
•
Dedicated GPON buffering
•
Two 10/100/1000 MACs with MII/RMII/GMII interfaces
•
33/50 MHz PCI 2.3 host, initiator/target interface
•
Dual Hi-speed USB 2.0 with integrated PHYs (support for host or
device modes)
•
Glueless interface to SLIC/SLACs and DAAs
•
Support for up to 32-channel cross-connects with TDM to TDM
and TDM to VoIP channel switching
•
Flash/SRAM controller
•
Hardware acceleration for IPSec (DES, 3DES, AES, MD5, SHA-1)
•
Two externaltimer outputs
•
Serial peripheral interface (SPI), Two-wire interface (TWI), Dual
UARTs
•
802.1x authentication engine
Voice Processing
•
Voice Coding G.711, G.729a, G.729ab, G.723.1
Software
The MSP7162 includes a turnkey-level software solution that
integrates the MaxMT Linux SDK with dedicated GPON APIs.
Applications developer can build high-performance, feature-rich
gateways quickly and easily in an environment consisting of:
•
Voice processing module (VPM) VoIP firmware suite
•
GPON protocol stack
•
GPON OMCI management stack
The MSP7162 and SDK are supported by standard tools from
industry leading vendors as well as GNU development tools
(compiler, debugger, EJTAG support, etc.)
Applications
•
Residential multi-service FTTH GPON gateway
•
SOHO GPON FTTH gateway
•
SMB GPON FTTH gateway
MSP7162 GPON Residential Gateway
GbE PHY
FE/GbE
switch
Transceiver
802.11a/b/g/n
chipset
Quad FXS
chipset
DDR2
Flash
USB 2.0
USB 2.0
VoIP
Subsystem
10/100/
1000BaseX
MAC
10/100/
1000BaseX
MAC
GPON
Subsystem
PCI I/F
DDR
Controller
Flash/SRAM
Controller
MSP7100
Series Core
USB Host/Device
USB Host/Device
GPON
MSP7162
Further Resources
PMC-Sierra Fiber-to-the-Home Solutions
Technical Documentation
About PMC-Sierra
PMC-Sierra is a leading provider of broadband communica-
tions and storage semiconductors for metro, access, fiber to
the home, wireless infrastructure, storage, laser printers, and
fiber access gateway equipment. PMC-Sierra offers worldwide
technical and sales support, including a network of offices
throughout North America, Europe, Israel and Asia. The
company is publicly traded on the NASDAQ Stock Market
