23
Underlined values indicate factory defaults.
*1 Changes in settings change menu settings.
FUNCTION
Sub menu Settings Description
FUNCTION 1 -
FUNCTION 5
HV DELAY
AUTOSETUP
BLUE ONLY
GAMMA SELECT
SD ASPECT
SCAN
SUB WINDOW
WFM/VECTOR
MARKER
PIXEL TO PIXEL
PIXEL POSITION
LEVEL METER
CROSS HATCH
MONO
TIME CODE
CLOSED
CAPTION
UNDEF
(Factory default:
FUNCTION1:
MARKER
FUNCTION2:
WFM/VECTOR
FUNCTION3:
PIXEL TO PIXEL
FUNCTION4:
TIME CODE
FUNCTION5:
LEVEL METER)
Selects functions to be assigned to [FUNCTION1] - [FUNCTION5]
(front panel buttons).
Displays synchronizing signals (horizontal, vertical).
The display changes in the following order.
DELAY OFF
J V DELAY J H DELAY J HV DELAY J DELAY OFF
Performs auto setup for PC display.
Cuts the red and green signals. Use this function to check phase and
chroma. This button toggles between ON and OFF.
*1
Displays the gamma curve.
The display changes in the following order.
GAMMA STANDARD J GAMMA FILM J GAMMA STDIO/PST J
GAMMA STANDARD
Switches between “16:9” and “4:3.”
*1
Switches between “UNDER SCAN” and “NORMAL SCAN”.
*1
Sets the split-screen function.
*1
The display changes in the following order.
SINGLE J FULL/PART J STILL J SINGLE
Displays waveform or vector display.
Turns the marker on and off.
Turns the PIXEL TO PIXEL function On and Off.
Positions the display of signals in PIXEL TO PIXEL mode.
Turns the LEVEL METER display On and Off.
Turns the time code display on and off.
Switches between color and monochrome.
Turns the closed caption display on and off.
Undefined
FUNCTION
DISPLAY OFF
ON1
ON2 Selects display of functions assigned to [FUNCTION1] -
[FUNCTION5] (front panel buttons). It also selects button action (1-
touch, 2-touch, off).
1-touch action to display and perform functions.
2-touch action to display and perform functions.
No function display.
Main Menu
(continued)
