RS-232 Communications Protocol & Command Set
BATTERY LEVEL STATUS
Requests the battery level, expressed as a percentage of maxi-
mum (full charge).
Send Query to UPS:
?BATTERYSTAT
Action:
Load level will be displayed
Response:
$BATTERY = xxx
xxx is the battery charge level (percentage of maximum charge)
expressed in decimal format. If the value is less than 100, the
hundreds digit is represented with a 0.
____________________________________________
LIST CONFIGURATION
Requests a list of all configurable parameters and current settings.
Send Query to UPS:
?LIST_CONFIG
Action:
List of configurable parameters and
current settings will be displayed.
Response:
$BTHRESH = level
$BUZZER = mode
$AVR = mode
$FEEDBACK = mode
LINEFEED = mode
$BRIGHTNESS = xxx
$SCROLL_MODE = xxx
$SLEEP_MODE = xxx
____________________________________________
List of all commands and queries
Send Query to UPS:
?HELP
Action:
List of all commands and queries
will be displayed
Response:
!ALL_ON
!ALL_OFF
!SWITCH
!SET_BATTHRESH
!SET_BUZZER
!SET_AVR
!SET_FEEDBACK
!SET_LINEFEED
!RESET_ALL
!SET_BRIGHT
?VOLTAGE
!SET_SCROLLMODE
!SET_SLEEPMODE
?ID
?LIST_CONFIG
?OUTLETSTAT
?HELP
?POWERSTAT
_________________________________________
RESPONSES & MESSAGES
OUTLET STATUS CHANGE
CONDITION
RESPONSE
Outlet Bank 1 changes state $BANK1 = status
Outlet Bank 2 changes state $BANK2 = status
status = {ON, OFF}
_________________________________________
POWER BUTTON STATUS CHANGE
CONDITION
RESPONSE
Power Button changes
$BUTTON = status
ON/OFF status
status = {ON, OFF}
_________________________________________
POWER FAULT STATUS CHANGE
CONDITION
RESPONSE
Overvoltage State
$PWR = OVERVOLTAGE
Undervoltage State
$PWR = UNDERVOLTAGE
Lost Power State
$PWR = LOST POWER
Test Mode
$PWR = TEST
Recovery Mode
$PWR = RECOVERY
Normal Operation Mode $PWR = NORMAL
Low Battery
$LOWBAT
AVR Stage
$AVRSTATE = state
state = {BOOST, BUCK}
Remaining Backup Time $TIME = xxx
xxx = backup time
Battery State
$BATTSTATE = xxx
xxx = {CHARGE, DISCHARGE, FULL}
Power Control Software
Complete Instructions are available by clicking on Help on the
Power Control Software welcome screen.
