- 8 -
. LAMP INDICATIONS
Red Flashing
Red Lit
Green Flashing quickly
Orange Lit
Orange Flashing
Charger is plugged into the AC outlet.
Ready to charge.
Now charging
Charging is completed.
Battery pack is warm. Charging will begin
when temperature of battery pack drops.
Charging is not possible. Clogged with
dust or malfunction of the battery pack.
. ACCESSORIES
Use only bits suitable for size of drill’s chuck.
RECOMMENDED SPEED SELECTION
CAUTION:
Use the following as a guide to select low or high speed for the job.
EY6950
DRILLING
MATERIAL/
CONDITION
SPEED
MORTAR / BRICK
WOOD /
YELLOW PINE
METAL METAL HOLE SAW
Thickness: 38 mm
(1-1/2") or less
Cold-rolled steel plate (SPC)
Thickness: 1.6 mm (1/16”) or less
HIGH
ø 13 mm (1/2")
or less
ø 25 mm (1")
or less
ø 13 mm (1/2")
or less
Not used
LOW Not recommended
ø 50 mm (2")
or less
ø 13 mm (1/2")
or less
ø 34 mm (1-11/ 32")
or less
