Installation/Connection

Installation method 1: DIN front mounting

Install the mounting sleeve into the dashboard.

Bend as many claws outward for tight fit, to lock the sleeve into the place.

Install the trim frame to the unit.

Use the rear mounting bolt to support the unit.
