Specifications
Dimensions
Power supply
Power consumption
DLP ™ chip Panel size
Display method
Pixels
Lens
Lamp
Screen size
Brightness* 1
Contrast ratio* 1
Resolution
RGB input scanning frequency
Component signal
Video signal
Lens shift
Keystone correction range
Terminals
DVI-D IN
RGB1/YP B P R IN
RGB2 IN
VIDEO IN
VIDEO OUT
S-VIDEO IN
LAN
SERIAL IN
SERIAL OUT
REMOTE 1 IN
REMOTE 1 OUT
REMOTE 2 IN
Optional board slot With ET-MD77SD1
installed* 3
With ET-MD77SD3
installed* 3
With ET-MD100SD4
installed
With ET-MD77DV
installed
Installation
Power cord length
Dimensions (W x H x D)
Weight*
4
Operating temperature
Operating humidity
Supplied accessories
* 1 Measurement, measuring conditions, and method of notation all comply with ISO 21118 international standards.
* 2 Only when using VESA CVT-RB(Reduced Blanking) signals.
* 3 The LAN terminal on each board, when mounted, cannot be used because the LAN terminal on the main unit has priority.
* 4 Average value. May differ depending on models.
* 5 The operating temperature range is 0°C (32°F) to 40°C (104°F) when used in High-Altitude mode (1,400 m [4,593 feet] to 2,700 m [8,858 feet]).
Also, if the ambient temperature exceeds 40°C (104°F) (35°C [95°F] in High-Altitude mode) when using all four lamps, the light output may be
reduced approximately 30% to protect the projector.
North America: 120–240 V AC, 16 – 9.0 A, 50/60 Hz (3-wire single-phase)
Europe, Asia: 220–240 V AC, 9.5 A, 50/60 Hz (3-wire single-phase)
North America: 1,600–1,500 W (10-15 W in standby mode with fan stopped)
Europe, Asia: 1,500 W (15 W in standby mode with fan stopped)
0.85" diagonal (16:9 aspect ratio)
DLP
™ chip x 3 (R, G, B), DLP ™ projection system
1,049,088 (1,366 x 768) x 3, total of 3,147,264 pixels
Optional powered zoom/focus lenses
300 W UHM lamp x 4 (four lamp system)
70 - 600 inches,16:9 aspect ratio
(70-300 inches, 16:9 aspect ratio with the ET-D75LE5)
10,000 lumens (four-lamp operation mode)
5,000:1 (full on/full off, in Dynamic iris 3 mode)
1,366 x 768 pixels (Input signals that exceed this resolution will be converted to 1,366 x 768 pixels.)
fH 15-100 kHz, fV 24-120 Hz
Dot clock 20-162 MHz
480i, 480p, 576i, 576p, 720/60p, 720/50p, 1035/60i, 1080/25p, 1080/24p,
1080/24sF, 1080/30p, 1080/60i, 1080/50i, 1080/50p, 1080/60p
fH 15.75/15.63 kHz, fV 50/60Hz
(NTSC,NTSC4.43,PAL,PAL60,PAL-N,PAL-M,SECAM)
Vertical: ±70% (±60% with the ET-D75LE6) (powered)
Horizontal: ±30% (±20% with the ET-D75LE6) (powered)
Vertical: ±40° (±22° with the ET-D75LE5, ±28° with the ET-D75LE6)
DVI-D 24-pin x 1, DVI 1.0 compliant, compatible with HDCP, single link
480p, 576p, 1080/60i, 1080/50i, 1080/24p, 1080/24sF, 1080/25p, 1080/30p, 1080/60p, 1080/50p,
720/60p, 720/50p
VGA (640 x 480) – WUXGA*
2 (1,920 x 1,200), compatible with non-interlaced signals only,
Dot clock: 25–162 MHz
BNC x 5
D-sub HD 15-pin x 1
BNC x 1, 1.0 Vp-p
BNC x 1, 1.0 Vp-p
Mini DIN 4-pin x 1
RJ-45 (10 Base-T/100 Base-TX) x 1, compatible with PJLink™
D-sub 9-pin female x 2 (RS232C x 1, RS422 x 1)
D-sub 9-pin male x 1 (RS422 x 1)
M3 jack x 1 for wired remote control
M3 jack x 1 for link control
D-sub 9-pin female x 1 for external control (parallel)
SERIAL IN: BNC x 1, SD-SDI signal (YC
B C R 4:2:2 10-bit): SMPTE 259M compliant: 480i, 576i
SERIAL OUT: BNC x 1, active through
SERIAL IN: BNC x 1, SD-SDI signal (YC
B C R 4:2:2 10-bit): SMPTE 259M compliant: 480i, 576i
Single-link HD-SDI signal (YC B C R 4:2:2 10-bit): SMPTE 292M compliant: 720/50p, 720/60p,
1035/60i, 1080/50i, 1080/60i, 1080/25p, 1080/24p, 1080/24sF, 1080/30p
SERIAL OUT: BNC x 1, active through
Link A/Link B IN: BNC x 1 for each, SD-SDI signal (YC
B C R 4:2:2 10-bit): SMPTE 259M compliant: 480i, 576i
Single-link HD-SDI signal (YC B C R 4:2:2 10-bit): SMPTE 292M compliant: 720/50p, 720/60p, 1080/50i,
1080/60i, 1080/25p, 1080/24p, 1080/24sF, 1080/30p
Dual-link HD-SDI signal (RGB 4:4:4 12-bit/10-bit): SMPTE 372M compliant: 1920 x 1080/50i,
1920 x 1080/60i, 1920 x 1080/25p, 1920 x 1080/24p, 1920 x 1080/24sF, 1920 x 1080/30p
Dual-link HD-SDI signal (X'Y'Z' 4:4:4 12-bit): 2048 x 1080/24p, 2048 x 1080/24sF
Specifications are the same as those for the DVI-D IN terminal on the main unit.
Front/rear, ceiling/floor
3.0 m (9.8')
578 x 320 x 643 mm (22-3/4" x 12-19/32" x 25-5/16") (without lens)
Approx. 35 kg (77.2 lbs) without lens
0 -45 °C (32 -113 °F)*
5
10-80% (no condensation)
Power cord, Wireless/wired remote control unit,
Batteries for remote control (3V AA battery x2), Eye bolt x4, Wire rope
Projection distance
unit: mm (inch)
Optional Accessories
643 (25-5/16")
578 (22-3/4")
Weights and dimensions shown are approximate. Specifications are subject to change without notice. This product
may be subject to export regulations. VGA and XGA are trademarks of International Business Machines Corporation.
All other trademarks are the property of their respective trademark owners.
Projection Images simulated.
DLP, DLP logo and DLP Medallion logo are trademarks or registered trademarks of Texas Instruments.
The PJLink trademark is an application trademark in Japan, the United States, and other
countries and regions or registered trademarks.
(C) 2008 Panasonic Corporation All rights reserved.
All information included here is valid as of October 2008.
PT-DW100-08October50K Printed in Japan.
Please contact Panasonic or your dealer for a demonstration.
http://panasonic.net/avc/projector
For more information about Panasonic projector ––
JQA-1617 EC98J2010
320 (12-19/32")
Throw distance
Diagonal image size
(aspect raio: 16:9)
ET-D75LE1
1.5-2.0:1
max. min.
ET-D75LE2
2.1-3.1:1
max. min.
ET-D75LE3
3.1-5.2:1
max. min.
ET-D75LE4
5.2-8.2:1
max. min.
ET-D75LE8
8.2-15.4:1
max. min.
ET-D75LE6
1.0-1.2:1
max. min.
ET-D75LE5
0.8:1
fixed
3,103 mm
10.2'
4,476 mm
14.7'
6,765 mm
22.2'
9,053 mm
29.7'
13,630 mm
44.7'
18,206 mm
59.7'
27,360 mm
89.8'
2,322 mm
7.6'
3,349 mm
11.0'
5,062 mm
16.6'
6,775 mm
22.2'
10,201 mm
33.5'
13,626 mm
44.7'
20,477 mm
67.2'
4,719 mm
15.5'
6,787 mm
22.3'
10,234 mm
33.6'
13,680 mm
44.9'
20,574 mm
67.5'
27,467 mm
90.1'
41,254 mm
135.3'
3,137 mm
10.3'
4,516 mm
14.8'
6,814 mm
22.4'
9,112 mm
29.9'
13,707 mm
45.0'
18,303 mm
60.0'
27,494 mm
90.2'
7,937 mm
27.9'
11,391 mm
39.9'
17,147 mm
59.9'
22,904 mm
79.9'
34,416 mm
119.9'
45,929 mm
159.9'
68,954 mm
239.9'
4,730 mm
15.5'
6,798 mm
22.3'
10,244 mm
33.6'
13,691 mm
44.9'
20,584 mm
67.5'
27,477 mm
90.1'
41,264 mm
135.4'
12,713 mm
41.7'
18,206 mm
59.7'
27,359 mm
89.8'
36,512 mm
119.8'
54,819 mm
179.9'
73,126 mm
239.9'
109,740 mm
360.0'
7,943 mm
27.9'
11,397 mm
39.9'
17,153 mm
59.9'
22,909 mm
79.9'
34,422 mm
119.9'
45,934 mm
159.9'
68,960 mm
239.9'
23,652 mm
77.6'
33,943 mm
111.4'
51,095 mm
167.6'
68,246 mm
223.9'
102,549 mm
336.4'
136,852 mm
449.0'
205,458 mm
674.1'
12,430 mm
40.8'
17,923 mm
58.8'
27,077 mm
88.8'
36,232 mm
118.9'
54,541 mm
178.9'
72,850 mm
239.0'
109,468 mm
359.1'
1,865 mm
6.1'
2,696 mm
8.8'
4,081 mm
13.4'
5,466 mm
17.9'
8,236 mm
27.0'
11,006 mm
36.1'
16,546 mm
54.3'
1,151 mm
3.8'
1,681 mm
5.5'
2,563 mm
8.4'
3,445 mm
11.3'
5,209 mm
17.1'
—
—
1,560 mm
5.1'
2,253 mm
7.4'
3,408 mm
11.2'
4,563 mm
15.0'
6,873 mm
22.6'
9,183 mm
30.1'
13,803 mm
45.3'
3-chip DLP ™ Projector
PT-DW100
Highly Reliable Wide 10,000 lm Projector
1. Do not install the projector in locations that are subject to excessive water, humidity, steam, or oily smoke. Doing so may result in fire,
malfunction, or electric shock.
2. The projector uses a high-voltage mercury lamp that contains high internal pressure. This lamp may break, emitting a large sound, or fail to
illuminate, due to impact or extended use.
3. The projector uses high-wattage lamp that becomes very hot during operation. Please observe the following precautions.
• Never place objects on top of the projector while it is in operation.
• Make sure there is an unobstructed space of 500 mm or more around the projector’s exhaust openings.
• Do not stack projector units directly on top of one another for the purpose of multiple (stacked) projection.
When stacking projector units, be sure to provide the amount of space indicated between them. These space requirements also apply to
installation where only one projector unit is operating at one time and the other unit is used as a backup.
• If the projector is placed in a box or enclosure, temperature of the air surrounding the projector must be between 0°C and 35°C. Also make sure the
projector’s intake and exhaust openings are not blocked. Take particular care to ensure that hot air from the exhaust openings is not sucked into the intake.
NOTES ON USE
4. If the projector is to be operated continuously 24 hours a day, use the multi-lamp optical system's alternating lamp operation (lamp changer)
function. The projector can be operated continuously 24 hours a day in four-lamp operation mode, but it will automatically operate with three
lamps for 8 hours of the 24 hours.
5. The lamp replacement cycle duration becomes shorter if the projector is operated repeatedly for short periods.
• The length of time that it takes for the lamp to break or fail to illuminate varies greatly depending on individual lamp characteristics and usage
conditions.
• The brightness of the lamp will gradually decrease with use.
6. Because the ET-D75LE5 is a fixed short-throw lens, the lens shift function cannot be used with it.
7. Due to natural characteristics of lamps, screen brightness may vary (flicker). This is not an indication of faulty lamp performance.
70"
100"
150"
200"
300"
400"
600"
Zoom lens
ET-D75LE6 (1.0-1.2:1)
ET-D75LE1 (1.5-2.0:1)
ET-D75LE2 (2.1-3.1:1)
ET-D75LE3 (3.1-5.2:1)
ET-D75LE4 (5.2-8.2:1)
ET-D75LE8 (8.2-15.4:1)
Fixed focus lens
ET-D75LE5 (0.8:1)
Lens
ET-D75LE1
Lamp
Replacement lamp unit
ET-LAD12K
ET-LAD12KF (four pack)
ET-PFD100
ET-HAD100
Frame
Carrying handle
Ceiling mount bracket
Smoke cut filter
Input signal board
SD-SDI input signal board
ET-MD77SD1
HD/SD-SDI input signal board
ET-MD77SD3
DVI-D input signal board
ET-MD77DV
Dual link HD/HD-SDI input
signal board
ET-MD100SD4
High-ceiling
mount bracket
ET-PKD100H
Low-ceiling
mount bracket
ET-PKD100S
ET-SFD100
This optional
smoke filter must be used
for staging events where
smoke or fog is dispersed.
ET-PKD100H
ET-PKD100S
Ecological-conscious design
Panasonic works from every angle to minimize environmental impact in the
product design, production and delivery processes, and in the performance of
the product during its life cycle. The PT-DW100 reflects the following
ecological considerations.
•Lead-free solder is used to mount components to the printed circuit boards.
•Lamp power switching further reduces power consumption.
•Auto Power Save activates standby mode when no signal is input.
Made in Japan
PT-DW100 projector is
carefully manufactured at
the Panasonic factory in Japan
under strict quality control. This is
another very important advantage
of Panasonic projectors.
