AMPLIFICATION

Power›Output:››110W›x›7›(1kHz,›THD›0.05%›@›8›ohms)

80W›+›80W›(20Hz›–›20kHz,›THD›0.08%›@›8›ohms›FTC)

AUDIO FEATURES

Freescale Dual-Core 400 MIPS Processing DSP

192›kHz/24-bit›DAC

Dolby

®

›TrueHD,›Dolby›Pro›Logic›IIz,›Dolby›Digital›EX,››

Dolby›Digital›Plus

DTS-HD

®

›Master›Audio,›DTS

®

›96/24,›DTS›Neo:6,›DTS›Express

WMA9 Pro

Neural-THX

®

Advanced MCACC Room Calibration with 9-band EQ

Symmetric›EQ,›Auto›Surround,›Stream›Direct,›Midnight›Listening›
Mode

Standing Wave Control

Multi-channel PCM (192 kHz) & SACD (multi-channel) Playback via
HDMI

0.1 Step Audio Delay (Lip Sync) (Max 10 Frame)

Advanced Surround (Action, Drama, Sci-Fi, Mono Film,
Entertainment Show, Expanded Theater, TV Surround, Advanced
Game, Sports, Classical, Rock/Pop, Unplugged, Extended Stereo)

Pioneer Jitter Reduction PLL Circuit

Phase›Control›(bass›management›ensures›precision›low›frequency›
output)

Front Stage Surround Advance (Focus, Wide)

Virtual Surround Back

Advanced Sound Retriever for enhanced PC and portable audio
(Multi-Channel)

Auto Level Control (Multi-channel)

Sound Retriever Air for Enhanced Bluetooth Audio Transmission

VIDEO FEATURES

Anchor›Bay

®

›1080p›Video›Scaler›–›HDMI›to›HDMI,›Analog›to›HDMI

CONVENIENCE

Works›with›iPhone

®

›Certified

-

Charges›iPhone›while›plugged›in›w/›supplied›USB/Video›Cable

-

Automatically›mutes›music›for›incoming›calls

-

All›iPhone’s›wireless›and›network›features›remain›functional

-

Available iControlAV app for receiver control via iPhone/iPod
Touch, available at the App Store

-

Full-color On-screen display including iTunes

®

album art

SIRIUS

®2

›Satellite›Ready

Internet Radio Ready w/ 24 Presets

Multi-zone Audio/Video (Zone 2) with On-screen Display

63 Tuner Presets

Learning Remote Control

FL›Dimmer›(4›steps)

Sleep›Timer

Auto›Audio›Signal›Select

LFE›Attenuator

CONNECTIVITY

HDMI v.1.4 (with 3D), Deep Color, and x.v.Color

-

6 Inputs (Including 1 Front Input) / 1 Output

Front›USB

Front›A/V›Inputs

Ethernet Input for Internet Radio

Bluetooth›Port›(Compatible›with›optional›Bluetooth›adapter›
AS-BT100)

Front›Mini›Jack

4 Digital Inputs (2 Coaxial, 2 Optical)

Component›Video›Terminal›(2›Inputs,›1›Output)›Assignable

Audio/Video›Inputs:›2A/4AV

Audio/Video›Output:›1A/1AV›+›1V

SR Input/Output, IR Input/Output, SIRIUS Input

Large›Speaker›Terminals›(FL/FR/C/SR/SL/SBR/SBL)

Subwoofer›Pre-Out

7.1-Channel A/V Receiver Featuring HDMI

®

1080p Video

Processing (v.1.4 with 3D), 7.1 Surround Sound,

Works with iPhone

®

Certification and Bluetooth Capability

1

VSX-1020-K

1

›Optional›Bluetooth›Adapter›(AS-BT100)›required.

2

›Antenna›and›subscription›required›and›sold›separately

Bold denotes›step-up›features›from›VSX-920-K
