Land Pride Snow Plow - Manual

1 © Copyright 2007 Printed
Before You Start
Your Snow Plow is exclusively designed for your Land
Pride NT & ST Treker. Please read these installation
instructions and your NT & ST Treker Operator’s Manual
thoroughly before beginning. Especially read information
relating to safety concerns. Also included in the
Operator’s Manual is important information on operation,
adjustment, troubleshooting, and maintenance for this
attachment (some manual sections do not apply to all
accessories).
General Information
These assembly instructions apply to the following Snow
Plow Accessories listed below:
701-067A NT 60" SNOW PLOW
701-068A ST 60" SNOW PLOW
Further Assistance
Your dealer wants you to be satisfied with your new
Snow Plow. If for any reason you do not understand any
part of this manual or are not satisfied with the service
received, the following actions are suggested:
1. Discuss the matter with your dealership service
manager making sure he is aware of any problems
you may have and that he has had the opportunity to
assist you.
2. If you are still not satisfied, seek out the owner or
general manager of the dealership, explain the
problem and request assistance.
3. For further assistance write to:
Land Pride Service Department
1525 East North Street
P.O. Box 5060
Salina, Ks. 67402-5060
E-mail address
[email protected]
When you see this symbol, the subsequent
instructions and warnings are serious - follow
without exception. Your life and the lives of
others depend on it!
!
IMPORTANT: Before you begin, read these
instructions and check to be sure all parts and tools
are accounted for. Please retain these installation
instructions for future reference and parts ordering
information.
!
DANGER
Exercise EXTREME CAUTION when plowing. Always plow at
a slow speed.
!
WARNING
TO AVOID SERIOUS INJURY OR DEATH:
1. DO NOT EXCEED 5 MPH WITH BLADE INSTALLED.
2. OPERATE WITH EXTREME CAUTION ON SLOPES,
STEEP GRADES, AND ROUGH TERRAIN.
3. KEEP AWAY FROM BLADE AND MOVING PARTS
DURING OPERATION.
4. WHEN PLOWING SNOW OR DIRT INTO A PILE, START
BACKING UP BEFORE RAISING THE BLADE.
5. DO NOT RAM THE BLADE INTO THE PILE. ** SLOW
DOWN BEFORE HITTING PILE. **
6. BE AWARE OF POSSIBLE HIDDEN OBJECTS UNDER
SNOW.
!
CAUTION
TO AVOID PERSONAL OR OTHER INJURY:
1. READ BLADE OWNER?S MANUAL, ATV OPERATOR?S
MANUAL, AND SAFETY DECALS BEFORE OPERAT-
ING.
2. WEAR HEAD PROTECTION, SAFETY GLASSES, AND
SHOES AS RECOMMENDED IN ATV OPERATOR?S
MANUAL.
3. ALLOW NO RIDERS ON BLADE OR ATV WHILE
MOVING OR STATIONARY.
4. KEEP BYSTANDERS AWAY FROM BLADE OR ATV
WHILE MOVING OR STATIONARY.
5. BEFORE ADJUSTING BLADE ANGLE STOP ATV
ENGINE, SET AND LOCK BRAKES, RAISE AND LOCK
BLADE IN UP POSITION. DO NOT ATTEMPT TO RAISE
BLADE BY HAND; USE THE LIFT HANDLE ONLY.
6. BEFORE ADJUSTING BLADE HEIGHT: LOWER
BLADE TO THE DOWN POSITION.
7. WHEN BLADE IS NOT IN USE, STOP ATV ENGINE, SET
AND LOCK BRAKES, AND LOWER BLADE TO DOWN
POSITION.
! ! ! OPERATION ! ! !
Your blade and hardware were designed with your safety
in mind. In order to protect you and your machine, certain
parts of the blade and / or hardware are designed to fail
when the equipment is over stressed. For this reason
Push Tubes, Blade Hinges, Foot Peg Brackets, Push
Plate Attaching Pins and Clevis Pins are not covered by
Warranty.
Blade angle is adjustable. Lock blade in the up position.
To move the blade left, right or straight, pull the Blade
Treker NT & ST Series
Snow Plow
Assembly Instructions
06/26/07
Manual No. 701-157M
