Chapter 5: Product Specifications
Efficient Networks
®
5800 Series
User Reference Guide
Page 5-2
Efficient Networks
®
Table 5-1: Front Panel Light Indications
Light
Color
Indications
PWR
Green
Off
Power is ON
Power is OFF
TEST
Yellow:
Green: (2 sec blink)
Off:
Running Power On Self Test
Self Test successful
Router is shut down
LINK
Yellow:
Green:
Off:
Establishing DSL modem link
DSL modem link successful
DSL modem link is shut down
WAN
Green flashing:
Off:
WAN transmissions detected
No WAN transmissions detected
LANT
Green flashing:
Off:
Transmitting LAN traffic
Not transmitting LAN traffic
LANR
Green flashing:
Off:
Receiving LAN traffic
Not receiving LAN traffic
