13

Connecting the Display

To arrange the cables

Connect the power cord and the signal cable as shown in the figure and then fix them

to the cable holders 1 and 2.

1.

Please insert the cable holder1
into the hole.

2.

Please put the power cord and

the signal cable in the cable holder 1.

3.

Please put the power cord and the signal cable in the cable holder 2.
While pressing the bottom of cable holder 2 with one hand, pull the top of
it with the other hand as shown in the picture.

Cable holder 1

NOTE

Use the cable holder to organize the cables in order to use the pivot function properly.
This picture shows how to organize cables generally and may look different from your product.

Press

Pull

Cable holder 2
