Lyngdorf Audio TDA 2200 - Manual (Page 40)

40
b. Protection
Parameter Value Note
Grounding Mains earth, chassis and audio
ground are connected
internally.
Output short circuit current ±40A
Output DC voltage ±5V @ <0.1Hz
Over temperature All heat sinks and mains-
transformer. Auto resetting thermal fuse in
mains transformer.
c. Mains
Parameter Value Note
Mains input connector IEC 320 cold type Mains lead supplied.
Mains voltage range 100-120V AC, 50–60Hz 115V version
Mains voltage range 200-240V AC, 50-60Hz 230V version
Internal mains fuse 8 Amp / 0.25A 115V version
Internal mains fuse 4 Amp / 0.1A 230V version
Power consumption 1.5 W STANDBY mode.
Power consumption 35 W OPERATE mode, no output.
Power consumption 116 W 2*37.5W/4ohms.
Power consumption 820 W 2*300W/4ohms.
d. Trigger
Parameter Value Note
TRIGGER OUT connector 3.5mm (1/8") mono jack Case=Gnd, Tip=Input
TRIGGER OUT Voltage 12V DC Short circuit protected
e. Mechanical
Parameter Value Note
Width 450mm (17.72")
Depth 435mm (13.39") Excluding loudspeaker
connectors (over wheel)
Depth 455mm (14.21") Including loudspeaker
connectors (over wheel.
Height 88.8mm (3.5") Excluding feet.
Height 100.6mm (3.96") Including feet.
Net weight 18.0Kg (37lb.)
Shipping weight 20.0Kg (41lb.)
