86217Ć2Ć AA (C) 4 Kohler Co., Kohler, WI
4.
Position the drawer unit on the
wall so the cleat that is
preĆinstalled on the back of the
unit rests on the cleat on the
wall. Make sure the unit is
centered on the cleat.
Measure 1/2" up from the
bottom inside edge and
approximately 1-2" from either
side. Drill a hole at each location
through the back of the box,
spacer block, and into the wall.
Use a drill of adequate diameter
to accommodate fasteners (not
provided).
Secure with fasteners (not
provided).
PreĆInstalled
Cleat
Drawer Unit
Wall Cleat
Finished Wall
DRAWER INSTALLATION
5.
Wax drawer guides with wax
crayon (provided). In order to
preserve the finish of this piece,
wax the drawer glides twice a
year.
Insert drawers.
CAUTION : RISK OF
PERSONAL INJURY
OR PRODUCT
DAMAGE. Be careful when
pulling out drawers. Drawers
slide completely out of the
cabinets. Provide support with
your hand underneath the
drawer when inserting or
removing drawers.
Wax
Crayon
Drawer
