Kohler 4EOZ - Manual (Page 9)

TP-6138 5/02
7
Group 3: Cylinder Head
Quantity
Part Variation No.
Item Number Description 1
1 GM24012 Head Assembly, Cylinder 1
2 GM23921 Valve, Breather 1
3 GM23941 Gasket, Cylinder Head 1
4 GM23878 Valve, Intake 1
5 GM23990 Washer 2
6 GM23876 Guide, Valve 2
7 GM23964 Guide, Oil Seal 2
8 GM23947 Spring, Valve 1
9 GM23895 Retainer, Valve Spring 2
10 GM24005 Valve, Cotter 2
11 GM23877 Valve, Exhaust 1
12 GM23894 Ring 1
14 GM23911 Rotocap, Valve 1
15 GM23948 Spring, Valve 1
16 GM23951 Spring, Retainer 1
17 GM23967 Stud, M5 x 10 2
18 # Washer, 5 mm ID 2
19 # Nut, Hex Head, M5 2
20 GM23872 Shaft, Rocker Arm 1
21 GM23919 Arm Assembly, Rocker 1
22 GM23918 Arm Assembly, Rocker 1
23 GM23889 Screw, Adjusting 2
24 # Nut, Hex Head, M7
25 GM23902 Injector, Fuel 1
26 GM23962 Washer 1
27 GM23903 Nozzle, Fuel Injector 1
28 GM23904 Seat, Spring 1
29 GM23905 Spring, Nozzle 1
30 GM23991 Flange, Injector 1
31 GM23972 Stud, M6 x 50 1
32 GM23971 Stud, M6 x 45 1
33 # Washer, Split, 6 mm ID 2
34 # Nut, Hex Head, M6 2
35 GM23987 Tube, Push Rod 1
36 GM23956 O-ring, 24 x 3.5 mm 1
37 # Plug, 22 mm 2
38 # Plug, 18 mm 1
39 GM23932 Gasket, Rocker Cover 1
40 GM23920 Cover, Rocker 1
41 # Washer, 5 mm ID 2
42 GM23989 Bracket, Lifting 1
44 GM23890 Nut, Collar 6
45 # Plug, 18 mm 1
47 GM23914 Switch, Temperature Alarm 1
48 GM23981 Washer, Copper, 14 mm ID 1
49 # Screw, Hex Head Cap, M8 x 20 2
50 # Washer, Split, 8 mm ID 2
52 GM23931 Gasket 2
53 GM23912 Thermostat 1
54 GM24140 Cover, Thermostat 1
# Common hardware; procure locally.
