Kohler Kitchen Sink Facet K-12177 User Manual
Page 6
Installation/Installation/Instalación
5
6
7
Partially thread screws into
the ring.
Visser partiellement les vis sur
l'anneau.
Enrosque parcialmente los
tornillos en el anillo.
Slide the fiber and metal washers onto the faucet shank. Thread the ring leaving
approximately 1/4" (6 mm) between the ring and the sink.
Glisser les rondelles en fibres et métalliques sur le manche du robinet. Visser
l'anneau en laissant approximativement 1/4" (6 mm) entre l'anneau et l'évier.
Deslice las arandelas de fibra y de metal en el vástago de la grifería. Enrrosque
el anillo dejando aproximadamente 1/4" (6 mm) entre el anillo y el fregadero.
1/4"
(6 mm)
Fiber Washer
Rondelle en fibres
Arandela de fibra
Metal Washer
Rondelle métallique
Arandela de metal
Ring
Anneau
Anillo
Insert the faucet through the sink.
Insérer le robinet dans l'évier.
Inserte la grifería a través del fregadero.
1004626-2-B
