En-4 | KTC-HR200
Operations –CD Receiver–
Tuning
Selecting the station.
1 Select HD Radio source
Press the [SRC] button.
Select the "HD Radio"/"HD RADIO" display.
2 Select the HD FM band
Press the [FM] button.
Each time the [FM] button is pressed it switches
between the HF1, HF2, and HF3 bands.
Select the HD AM band
Press the [AM] button.
3 Tune up or down program
Press the [ 4] or [¢] button.
If the sub channel is available in Digital FM
broadcast when is set to Auto
seek or Manual, the channel can be switched.
Example:
(HD FM band)
Analog FM 1
Digital FM 2 Analog FM ™
Digital FM-1ch 3 Analog FM £
Digital FM-2ch 4
Digital FM-8ch 0
Digital FM !
…
: Auto seek or Manual
: Auto mode
[ 4]
[ ¢]
• During the reception of 1, tune up:
2 ➡3➡4…
• During the reception of !, tune down: ! ➡0…
⁄
• Using the modes can be switched to
digital broadcast automatic switching, analog broadcast
only, or digital broadcast only.
• When "Digital" has been set with , the
seek time will be longer to allow a check of whether the
transmission is a digital broadcast.
• It will take few seconds to receive the digital
broadcasting after selecting the frequency.
• When Tune up button is pressed, it will switch to the
next frequency if is it switched before receiving the
Digital broadcasting. (™
➡£)
• When Tune down button is pressed, it will be received
from Analog broadcasting if the Digital broadcasting has
never been received. (!
➡£)
• When is set to "Manual", the frequency
will be switched while pressing [ 4] or [¢] buttons.
• Some of the models have the following displays when
the Main channel and Sub channel are switched.
- "Main"/"Primary"/"PRI": When it is switched to the Main
channel
- "Sub"/"Secondary"/"SEC": When it is switched to Sub
channel
Tuning Mode
Sets the tuning mode.
Press the [AUTO] button.
Each time the button is pressed the Tuning mode
switches as shown below.
