Shoprider GK8 - Manual (Page 11)

3/17/2005 11
DRIVE/FREEWHEEL OPERATION (FIG 8)
The drive/freewheel lever (yellow ball handle) is located under the seat at the right rear of
unit. This lever allows you to disengage the drive mechanism and push the scooter while in
freewheel mode. To disengage the drive mechanism (neutral), move the lever forward (the
scooter can now be pushed). To re-engage the drive mechanism (drive), move the lever
backward (now the unit may be driven).
Note: The scooter will not operate while the drive/freewheel lever is in the neutral position
(forward). The scooter must be turned off, lever moved backward (drive position) and then
turned on in order to reset the circuits.
WARNING! Always re-engage the free wheeling device after use. Failure to do so
may result in injury.
Anti-tip wheels
The anti-tip wheels are located at the rear of the scooter frame (Fig 8). The scooter should
not be used unless the anti-tipping wheels are in place.
Shoprider® is not responsible for damage or injury incurred due to improper or
misuse of the scooter.
Scooter serial number
The scooter serial number is located on the seat post and consists of a combination of 13
numbers and letters. Shoprider recommends that you write the serial number down on the
back of this manual for future reference. Refer to Page 8, Fig 5.
Figure 8
Free Wheel
Lever (yellow)
Anti-Tip Wheels
Push Scooter
Drive Scooter
Charging Port
Circuit Breaker
(Reset Button)
Detach Lever
(yellow)
