Ceiling-Mount Setup Guide
Components
Main
Assy
(1)
Pipe
(Left 1,
Right
1)
Top-
Plate(1)
Safety
Guide
Pin(2)
Plastic
Hanger
(4)
Nut(1) Screw
(A)(2)
Screw
(B)(4)
Screw
(C)(1)
Safety Instructions
Do not install this product by yourself. Contact the service technician Qualified by the man-
ufacturer.
Part and Assembly Process
Variance of Assembly
Introduction
