WARNING
To prevent fire or shock hazard, do not
expose the unit to rain or moisture.
Welcome !
Thank you for purchasing the Sony
WM-FX665/FX663/FX661 Radio
Cassette Player.
Some features are:
•You can enjoy low bass sounds by
the powerful headphone.
• You can choose from 2 different
emphasizing tones: MB (MEGA
BASS) and GRV (GROOVE) to
adjust to your favorite sound.
• LCD Menu function that lets you
select and switch functions in the
display window of the main unit.
• Auto Memory Scanning function
that lets you store and recall up to
16 stations for FM and 8 stations
for AM automatically.
• AMS (Automatic Music Sensor)
function that searches the
beginning of the current and 2
previous tracks, and succeeding 3
tracks at high speed.
• Useful remote control.
z
Getting Started
Preparing a Power
Source
Choose one of the three power
sources below; dry battery,
rechargeable battery, and mains.
Dry Battery
(see Fig. A-a)
Attach the supplied battery case,
and then insert one R6 (size AA)
battery with correct polarity.
Notes
• Do not charge a dry battery.
• When you are not going to use your
Walkman for a long time, remove
the battery to prevent damage from
battery leakage and corrosion.
Rechargeable Battery
(see Fig. A-b)
1
Insert the rechargeable battery
(NC-6WM) into the charger
with correct polarity.
2
Plug in the charger to the
mains.
UK, Australia and Hong Kong
model: Full charging takes
about 3.5 hours.
North, Central and South
America, European Continent,
and Saudi Arabia models :
Full charging takes about 2.5
hours.
Korean model : The full
charging time depends on the
voltage of your mains.
110 V: 10 hours
220 V: 2.5 hours
Other models: The full
charging time depends on the
voltage of your mains.
120 V: 10 hours
220–240 V: 2.5 hours
If the plug does not fit your
mains, attach the supplied AC
plug adaptor. (Excluding
Chinese models)
3
Insert the fully charged battery
into the rechargeable battery
compartment (see Fig. A-c).
You can charge the battery about
300 times.
(turn over)
Notes
• Do not tear off the film on the
rechargeable battery.
• Use only the supplied battery
charger to charge the supplied
rechargeable battery.
• Remove the charger unit from the
wall outlet as soon as possible after
the rechargeable battery has been
charged. Overcharging may damage
the rechargeable battery.
• The battery charger and the
rechargeable battery may become
warm during charging, but it is not a
problem.
• Be sure not to short-circuit the
battery. When you carry it with you,
use the supplied carrying case. If
you do not use the carrying case, do
not carry with other metallic objects
such as keys in your pocket.
When to replace/charge
the battery
(see Fig. A-d)
Replace or charge the battery when
the BATT lamp dims.
Battery life
(Approx. hours)(EIAJ*)
Tape
Radio
playback reception
Rechargeable
8
9
battery (NC-6WM)
Sony alkaline
29
30
LR6 (SG)
Sony R6P (SR)
8
8
Rechargeable
battery (NC-6WM)
and Sony
36
37
alkaline LR6 (SG)
* Measured value by the standard
of EIAJ (Electronic Industries
Association of Japan). (Using a
Sony HF series cassette tape)
Note
• The battery life may shorten
depending on the operation for the
unit.
For maximum performance we
recommend that you use an alkaline
battery.
House Current (mains)
(see Fig. A-e)
Remove the rechargeable battery if
inserted and attach the battery case.
Connect the AC power adaptor AC-
E15HG (not supplied) to the DC IN
1.5 V of the battery case and to the
mains. Do not use any other AC
power adaptor.
Specifications for AC-E15HG varies
for each area. Check your local
voltage and the polarity of the plug
before purchasing.
Polarity of
the plug
Connecting the
Headphones
(see Fig. B)
1
Connect the micro plug firmly
to the remote control. (FX665/
FX663 only)
2
Connect the remote control to
2REMOTE.
3
Wear the “L” marked side to
the left ear and “R” marked
side to the right ear.
If the earphones do not fit to
your ears or the sound is
unbalanced, turn around the
earphones a little to fit to your
ears firmly.
Releasing HOLD
(see Fig. C)
The HOLD function locks the
Walkman to prevent from operating
when you accidentally press a
button. If the Walkman is locked,
unlock it before operating.
1
Slide HOLD to the opposite
direction of the arrow.
To lock the Walkman
Slide HOLD in the direction of the
arrow.
To lock and unlock the
remote control
See “Using the Remote Control”.
z
Operating the
Walkman
Playing a Tape
(see Fig. D-a)
The Auto Tape Selector
automatically selects the tape
(normal (TYPE I), CrO
2
(TYPE II) or
metal (TYPE IV) ) for playback.
1
Insert a cassette.
2
Press ϥREPEAT to start
playing then adjust the volume.
When adjusting the volume on
the Walkman
Set the VOL control on the remote
control at maximum.
When adjusting the volume on
the remote control
Set the VOLUME control on the
Walkman to around 6.
To operate using the remote
control
See “Using the Remote Control”.
To
Press (see
Fig. D-b)
play the other side
ϥREPEAT
during playback
stop playback
p
fast forward
FF•AMS
during stop
rewind
REW•AMS
during stop
repeat the track
ϥREPEAT
you are listening to
for two seconds
(Repeat Single
or more during
Track function)
playback
To stop a
single repeat,
press it again.
find the beginning
FF•AMS once/
of the next track/
repeatedly
succeeding 3 tracks
during
(AMS*)
playback
find the beginning
REW•AMS
of the current track/
once/
previous 2 tracks
repeatedly
(AMS*)
during
playback
(continued)
English
The instructions in this manual are for WM-FX665, WM-FX663 and WM-FX661.
Before you start reading, check your model number. WM-FX665 is the model
used for illustration purposes. Any differences in operation are clearly indicated
in the text, for example, “FX665 only”.
a
FX661
2 REMOTE
2 REMOTE
HOLD
OPEN
BL
SKIP
NR
SOUND
MODE
FM
MODE
AVLS
MENU
SET
BATT
SET
MENU
ON
ON
FWD
Sony Corporation © 1998 Printed in Malaysia
3-862-488-62 (1)
Radio Cassette Player
c
b
2 REMOTE
FX665
A
FX663
FX661
a
b
UK, Australia and
Hong Kong models
d
BATT lamp
e
DC IN 1.5 V
c
•
•
•
•
•
A d
*
*
•
A e
°
1
2
2
3
C
1
z
D a
1
2
ϥ
D
b
œ •
p
•
•
œ •
•
*
•
*
•
•
*
•
• – – –
•• – – –
*
D c
*
D c
a
Å
•
D c
a
*
a
•
•
•
•
•
•
z
A a
•
•
A b
1
2
3
A c
Operating Instructions
WALKMAN is a registered trademark of Sony Corporation.
WM-FX665/FX663/FX661
Other models
FX665
FX663
play the other side
FF•AMS for two
from the beginning
seconds or
(Skip Reverse
more during
function)
stop
play the same side
REW•AMS
from the beginning
for two
(Rewind Auto
seconds or
Play function)
more during
stop
* Automatic Music Sensor
Note on Beeps during AMS
operations
• The beeps differ in relation to the
track number being searched. When
finding the beginning of the next 3
tracks during AMS operations,
beeps “• – – –” (beep followed by
three long beeps) are emitted
repeatedly. Likewise, when finding
the beginning of the previous 2
tracks, beeps “•• – –␣ –” are emitted
repeatedly. While the remaining
tracks are reduced, the number of
long beeps are reduced accordingly.
To skip a long blank space
between musics. (BL SKIP*
function) (see Fig. D-c)
Press MENU repeatedly to set the
cursor to BL SKIP in the display.
Then press SET to show “ON”.
* The Walkman fast forwards the tape
to the next track if there is a blank
space longer than 12 seconds.
To select playback mode
(see Fig. D-c)
Press MENU repeatedly to set the
cursor to MODE in the display.
Then press SET to select the desired
mode.
To play
Select
Both sides repeatedly
a
Both sides once
Å
from the side facing
the cassette holder
Note on AMS, REPEAT Single
Track and BL SKIP
• To operate the AMS and the
REPEAT Single Track functions, you
need a blank of 4 seconds or longer
between the tracks. For the BL SKIP
function, you need a blank of 12
seconds or longer. Therefore, if there
is noise between the tracks, these
functions will not detect the blank
and will not operate. Likewise, if the
recording level is moderately low
within a track, these functions may
inaccurately operate.
To play a tape recorded with
Dolby* NR system
(see Fig. D-c)
Press MENU repeatedly to set the
cursor to a NR (Dolby noise
reduction) in the display. Then
press SET to show “ON”.
* Dolby noise reduction manufactured
under license from Dolby
Laboratories Licensing Corporation.
“DOLBY”and the double-D symbol
a are trademarks of Dolby
Laboratories Licensing Corporation.
