Sanyo AHX0752 User Manual

Test run service manual

TEST RUN SERVICE MANUAL

R410A Models

Indoor Units

Class

4-Way Air Discharge Semi-Concealed

XHX1252 XHX1852 XHX2452 XHX3652

1-Way Air Discharge Semi-Concealed AHX0752 AHX0952 AHX1252

U Concealed-Duct

UHX0752

UHX1252 UHX1852 UHX2452 UHX3652

D Concealed-Duct High-Static Pressure

DHX3652 DHX4852

Ceiling-Mounted

THX1252

THX1852

THX2452

Wall-Mounted

KHX0752 KHX0952 KHX1252 KHX1852 KHX2452

Outdooe Units

Class

140

C ECO-i W-2WAY

CHDX09053

CHDX14053

85464849257000

REFERENCE NO.

SM830157

This manual is related to the following products:

ECO-i CHDX09053 DHX3652
