SFT-1 TECHNICAL SPECIFICATIONS
Wow and Flutter Below measurable levels
Jitter <2 ps rms, to 40 kHz at the clock
Typically 10 ps rms, at the outputs
(independently verified with UltraAnalog’s
latest Jitter Analyzer)
Digital Outputs
AES/EBU Balanced on XLR-3 connector
Impedance 110 ohms, ±5%
Level 3.0V p-p typ with 110 ohm load
Tr=Tf 7 ns, typ
SPDIF Single ended RCA connector
Impedance 75 ohms, ±5%
Level 0.5V p-p typ with 75 ohm load
Tr=Tf 8 ns, typ
SPDIF Single ended BNC connector
Impedance 75 ohms, ±5%
Level 0.5V p-p typ with 75 ohm load
Tr=Tf 8 ns, typ
Glass-ST HP HFBR-1414
Power 60 uw into 62 um fibre
Laser, Semiconductor GaAIAs, 0.5 mw, continuous, 790 nm
Sampling Rate 352.8 KHz
Disc Rotation Velocity 200-500 rpm (constant linear vel.)
Quantization 16 bits, linear
Error Correction CIRC principle
Number of channels 2 channels, stereo
Dimensions 17” Wide x 11” Deep x 3.5” High
(43 cm x 28 cm x 9 cm)
Weight 17 lbs (7.7 kg), unpacked
Warranty 5 years parts and labor on the unit
1 year on transport mechanism
This symbol is intended to alert the
user to the presence of uninsulated
“dangerous voltage” within the
product’s enclosure that may be of
sufficient magnitude to constitute
a risk of electric shock to persons.
This symbol is intended to alert the
user to the presence of important
operating and maintenance (servicing)
instructions in the literature accompany-
ing the appliance.
D a n g e r - Invisible Laser radiation when the
cover is removed from the chassis. Avoid dire c t
e x p o s u re to the beam.
Wa rn i n g - Fast heating (eg. bringing the
mechanism from a cold place into a warm and
humid room) can result in moisture condensing
on the lens. Before operation, the mechanism
should stabilize for at least 4 hours.
