ATA C

OMMANDS

SSD-D

XXX

(

X

)-5000 D

ATA

S

HEET

[P

RELIMINARY

]

S

ILICON

S

YSTEMS

P

ROPRIETARY

This document and the information contained within it is confidential and proprietary to SiliconSystems, Inc.

All unauthorized use and/or reproduction is prohibited.

5000D-00DSR PRELIMINARY

P

AGE

11

M

ARCH

16, 2009

53

0007h

Field validity:

2

1 = Fields reported in word 88 are valid

1

1 = Fields reported in words 64-70 are valid

59

0101h

8

1 = Multiple sector setting is valid

7-0

Xxh = Current setting for number of sectors
that shall be transferred per interrupt on R/W
Multiple command

60-61

XXXXh

-

Total number of user addressable sectors

63

XXX7h

10

1/0 = Multiword DMA mode 2 is selected/not
selected

9

1/0 = Multiword DMA mode 1 is selected/not
selected

8

1/0 = Multiword DMA mode 0 is selected/not
selected

2

1 = Multiword DMA mode 2 and below are
supported

1

1 = Multiword DMA mode 1 and below are
supported

0

1 = Multiword DMA mode 0 is supported

64

0003h

7-0

PIO modes supported

65

0078h

Minimum Multiword DMA transfer cycle time
per word:

15-0

Cycle time in nanoseconds

66

0078h

Manufacturer’s recommended Multiword DMA
transfer cycle time:

15-0

Cycle time in nanoseconds

67

0078h

Minimum PIO transfer cycle time without flow
control:

15-0

Cycle time in nanoseconds

68

0078h

Minimum PIO transfer cycle time with IORDY
flow control:

15-0

Cycle time in nanoseconds

Table 10: IDENTIFY DEVICE Information (Continued)

Word

Value

Description
