6-48
Chapter 6 Technical Descriptions
Chapter 6 Technical Descriptions
6-3 Central Section Panels
6 SPLIT Push-Button
All 6 external source selections will normally feed both Control Room
Monitor LS and Studio LS outputs. If {SPLIT} is selected, the upper pair of
SELECT SOURCE buttons feed the studio LS only, and the lower 4
selectors feed the Control Room Monitors. Their {MIX} functions are also
separated.
7 MON ( Indicators
Are displayed when {SPLIT} is selected and indicate that the four lower
external sources will feed the CR Monitor LS only.
8 9 SLS Indicator
Is displayed when {SPLIT} is selected and indicates that the two upper
external sources will feed the Studio LS only.
