MAINTENANCE
 Careful maintenance ensures a tight seal between the sleeve and
nozzle, improving sound quality and product safety.

Keep the earphones and sleeves as clean and dry as possible.
 Do not expose earphones to extreme temperatures.
 Wipe the earphones and sleeves with mild antiseptic to avoid
infections. Do not use alcohol-based disinfectants.
CERTIFICATION
Eligible to bear CE marking.
Conforms to European EMC Directive 89/336/EEC.
Meets applicable tests and performance criteria in European Standard
EN 55103 (1996) Parts 1 and 2, for residential (E1) and light industrial (E2)
environments.
FURNISHED ACCESSORIES
Carrying pouch . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 95A2259
Fit Kit w/cleaning tool . . . . . . . . . . . . . . . . . . . . . . . . 90XJ1371
Triple flange sleeves . . . . . . . . . . . . . . . . . . . . . . . . . 90WX1371
Replacement nozzles . . . . . . . . . . . . . . . . . . . . . . . . 90XF1371
Plug adapter — 1/8” to 1/4” . . . . . . . . . . . . . . . . . . . PA234
REPLACEMENT PARTS
Bag of 20 foam sleeves . . . . . . . . . . . . . . . . . . . . . . . PA750
Bag of 500 foam sleeves . . . . . . . . . . . . . . . . . . . . . . PA754
Bag of 10 clear flex sleeves:
small . . . . . . . . . . . . . . . . PA756S
medium . . . . . . . . . . . . . . PA756M
large . . . . . . . . . . . . . . . . . PA756L
Bag of 10 soft flex sleeves:
small . . . . . . . . . . . . . . . . PA758S
medium . . . . . . . . . . . . . . PA758M
large . . . . . . . . . . . . . . . . . PA758L
Triple-flange sleeves (2). . . . . . . . . . . . . . . . . . . . . . . PA755
Replacement nozzles (2) . . . . . . . . . . . . . . . . . . . . . . PA4NC
SAFE USE
 Use a slow twisting motion to remove the earphones. Never pull
on the earphone cord.

Warning: If a sleeve becomes lodged in your ear, seek skilled
medical assistance to remove the sleeve. Damage to the ear
may be caused by non-professionals attempting to remove the
sleeve.
 Prior to inserting the earphone, always recheck the sleeve to
make sure it is firmly attached to the nozzle.
 Turn up the volume control only far enough to hear properly.
 Ringing in the ears may indicate that the volume level is too high.
Try lowering the volume.

If you connect these earphones to an airplane’s sound system,
listen at low levels so that loud messages from the pilot do not
cause discomfort.

Have your ears checked by an audiologist on a regular basis. If
you experience wax buildup, discontinue use until an audiologist
has examined your ears.
 Stop using the earphones if they are causing great discomfort or
infection.
REPLACING THE EARPHONE NOZZLE
Replace the nozzle if it becomes damaged, or if wax buildup cannot be removed
using the wax removal loop.
Unscrew the retainer  from the earphone base .
Remove the nozzle .
Slide the retainer  over the new nozzle .
Place the nozzle on the earphone base with the flange  aligned with the
groove in the base. Tighten the retainer .
Be careful when replacing the earphone nozzle. Parts are small and easily lost if
dropped.
1.
2.
3.
4.
� � �
�
TECHNICAL SPECIFICATIONS
Transducer type Single balanced armature
Sensitivity (at 1kHz) 109 dB SPL/mW
Impedance (at 1kHz) 29 W
Output connector Gold-plated 3.5 mm (1/8-inch) stereo plug
Net weight 31 g (1.1 oz.)
Operational temperature -18° C to 57° C (0° F to 135° F)
Storage temperature -29° C to 74° C (-20° F to 165° F)
CUSTOM EARPHONE SLEEVES
Those who use earphones regularly for extended periods of time often find
custom-fit molded sleeves offer the best comfort and sound isolation.
Ask a Hearing Health Care Professional about creating custom molded sleeves
for your earphones. For more information, visit http://www.sensaphonics.com.
EARSUPPORT
Install the earphone in the EarSupport as
shown. The EarSupport secures the cable
comfortably behind the ear.
