QUICKIE GTX PAGE 37
NON- FOLDING BACKREST HARDWARE
Note: for chairs built prior to July 20 2007 S/N F3­134556 you must replace both backrest brackets by ordering 103543­001 or 103543­002.
Pos. Item Number Description Remarks
1 103470 WASHER PIVOT BACKREST
2 102263-001 SHCS M6 x 1 x 16 INORGANIC
3 102262-007 BHCS M6 x 1 x 45 INORGANIC
4 102262-002 BHCS M6 x 1 x 10 W/PL INORG
5A 103490-001 BRACKET BACKREST 22MM USED WITH SOLID BACK INSERT.
5B 103490-002 BRACKET BACKREST 22MM EXT USED ON NON-HEAVY DUTY CHAIRS.
6 103679 SLEEVE BRACKET BACKREST .088
7 103472 SADDLE BACKREST NON-FOLD
8 200113 NUT HEX NYLOCK M6 X 1 NUT
9 250104 WASHER FLAT M6
10 262130 6MM WASHER WAVE
11 103537 FOLDING BACK CONVERSION KIT
12 561082 1" TUBE END BUSHING THIN
